Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Motor MAHLE hub-drive -
Battery Mahle-Ebikemotion, integrated, non-removable -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Judy Silver TK, TurnKey damper, Solo Air spring, compression adjust (low-speed to lock), rebound adjust, 40mm offset
Rear Shock
None
Drivetrain
Rear Derailleur
Shimano Deore M5120, 10-speed, SGS cage, SHADOW RD+
Front Derailleur
None
Shift Levers
Shimano Deore M4100, 10-speed, RAPIDFIRE+
Cassette
Shimano Deore HG500, 10-speed, 11-42 tooth
Crank
Samox, 155mm length
Chain
Shimano HG54, 10-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Front: Formula DC20LW, 9x135mm, Rear: Mahle-Ebikemotion X-35, 9mm, HG driver
Rear Hub
Front: Formula DC20LW, 9x135mm, Rear: Mahle-Ebikemotion X-35, 9mm, HG driver
Rims
MDK-XP1, 23mm internal width, tubeless ready, 32 hole
Spokes
CN round stainless steel
Tires
Kenda Booster, single compound, 30 TPI, wire bead, 24" x 2.4"
Brakes
Brakes
Tektro Auriga HDM291, 2-piston, 160mm 6-bolt rotors
Brake Levers
Tektro Auriga HDM291
Cockpit
Stem
MDK XC, 6061 forged alloy, 35mm length, 31.8mm bar clamp, 0° rise
Handlebar
MDK XC 1.0, 6061 alloy, 25mm rise, 580mm width, 9° backsweep, 5° upsweep, 31.8mm clamp diameter
Grips
Onoff Twin, single lock-on, 135mm length
Headset
Onoff Saturn, sealed angular contact bearings
Seat
Saddle
SDG Fly JR
Seatpost
MDK XC 0-R, 6061 T6 alloy, 300mm length
Motor & Battery
Motor
Mahle-Ebikemotion X-35 rear hub
Battery
Mahle-Ebikemotion, integrated, non-removable
Fit data
Geometry
Numbers for sizing and ride feel.
About this model
Play 24 completes the Mondraker E Play model. Mondraker released 9 e-bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Mountain e-bikes
Our math shows that the average cost of a dependable Mountain e-bike is 1448$. However, even though the average price of a Mountain e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Mountain e-bikes average weight
The average weight for Mountain e-bikes is 24.45 kg (53.9 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Mondraker Play 24 it’s weighing 15.1 kg (33.29 lbs). At this weight, is much lighter than average. In conclusion, the average Mountain e-bike weighs 61.92% more than Play 24.
Play 24 components
Fork
This e-bike has the RockShox Judy Silver TK fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Play 24 2021 e-bike is equipped with 24″ aluminum wheels when leaving the factory. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
When you want to stop the bike in time, the brakes are vital. The Play 24 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
