Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID Select
-
Groupset NX Eagle, Truvativ Stylo -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox SID Select Charger RL, DebonAir, 2 position remote compression (open/lock), 42mm offset
Rear Shock
None
Drivetrain
Rear Derailleur
SRAM NX Eagle 12-speed
Front Derailleur
None
Shift Levers
SRAM NX Eagle 12-speed
Cassette
SRAM XG-1230 11-50 tooth 12-speed
Crank
Truvativ Stylo 6K DUB Eagle, 170mm on S and 175mm on M/L/XL
Bottom Bracket
SRAM DUB PF30
Chain
SRAM NX Eagle 12-speed
Chain Guide
None
Pedals
N/A
Wheels
Front Hub
Mavic Boost, sealed bearing, ID360 rear
Rear Hub
Mavic Boost, sealed bearing, ID360 rear
Rims
Mavic Crossmax, 25mm internal width, asymmetric, tubeless ready, 24 hole
Spokes
Mavic steel
Tires
Maxxis Ikon 29x2.2", 3C MaxxSpeed compound, tubeless ready, 120TPI, folding bead, front and rear
Brakes
Brakes
Shimano MT501, with 160mm RT56 IS 6-bolt rotors, resin pads
Brake Levers
Shimano MT501
Cockpit
Stem
Stealth Carbon Integrated, 31.8mm clamp, 75mm (S/M), 90mm (L), or 105mm (XL) reach
Handlebar
Onoff Sulfur 0.2, rise: 4.8mm, width: 760mm, 9° backsweep, 0° upsweep, 31.8mm clamp
Grips
Onoff Twin, 1lock-on, 135mm
Headset
Onoff Titan, ACB sealed bearings, top 41.8x30.5x8x45°x45°, bottom 51.9x40x8x45°x45°
Seat
Saddle
Fizik Antares R7
Seatpost
OnOff Sulfur 0-R, 6061 T6 Alloy, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm | 1.5 mm | 1.48 mm |
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm | 300 mm |
| Stack | 632 mm | 637 mm | 646 mm | 661 mm |
| Reach | 397 mm | 415 mm | 432 mm | 447 mm |
| Top Tube Length | 585 mm | 605 mm | 625 mm | 645 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 395 mm | 430 mm | 470 mm | 520 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 85 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1081 mm | 1101 mm | 1122 mm | 1142 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Podium Carbon belongs to the Mondraker Podium model. There are 12 bikes that carry this model name. You can easily view all of the Mondraker Podium bikes models from 2020, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Crosscountry bikes
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Mondraker Podium Carbon it’s weighing 10.2 kg (22.49 lbs). At this weight, is much lighter than average. In other words, this model is 21.57% lighter than the average Crosscountry bike.
Overview of components
Fork
The Podium Carbon comes factory-installed with the RockShox SID Select fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Mondraker Podium Carbon 2020, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Mondraker Podium Carbon is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Podium Carbon comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
