Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID SL Select
-
Groupset GX Eagle, Truvativ Stylo -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox SID SL Select RL 29, Charger, Debonair, Boost 15x110mm axle, 32mm aluminum stanchions, 44mm offset, Settings: OneLock 2-position remote compression (open/lock), low-speed rebound, air preload
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12-speed, X-Actuation 1:1
Front Derailleur
N/A
Shift Levers
SRAM Trigger GX Eagle, 12-speed, X-Actuation 1:1
Cassette
SRAM XG-1275, 10-50 tooth, 12-speed
Crank
Truvativ Stylo 7K Eagle, Boost, DUB axle, size S: 170mm, size M/L/XL: 175mm
Bottom Bracket
SRAM DUB BSA, sealed bearings, 73mm
Chain
SRAM NX Eagle, 12-speed, Powerlock
Chain Guide
None
Pedals
None
Wheels
Front Hub
Front: DT Swiss 370, Boost 15x110mm, IS 6 bolts, Rear: DT Swiss 370, Boost 12x148mm, 3-pawl system, IS 6 bolts, XD freehub
Rear Hub
Front: DT Swiss 370, Boost 15x110mm, IS 6 bolts, Rear: DT Swiss 370, Boost 12x148mm, 3-pawl system, IS 6 bolts, XD freehub
Rims
DT Swiss X 1900 Spline 29, 25mm internal width, sleeved aluminum, tubeless ready, 28 hole
Spokes
DT Swiss Competition, straightpull
Tires
Maxxis Ikon 29"x2.20", 3C MaxxSpeed compound, tubeless ready, 120 TPI, folding bead
Brakes
Brakes
SRAM Level TLM, 2-piece caliper, Centerline 160mm IS 6-bolt one-piece rotors, steel-backed organic pads
Brake Levers
SRAM Level TLM, Direct Link actuation, tooled reach adjust, lever pivot bushings
Cockpit
Stem
MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5°, length: sizes S/M: 60mm, size L: 70mm, size XL: 80mm
Handlebar
ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 740mm, 9° backsweep, 0° upsweep, 31.8mm barbore
Grips
ONOFF Twin, single lock-on, 135mm
Headset
ONOFF Titan tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41.8x30.5x8x45°x45°, bottom 51.9x40x8x45°x45°
Seat
Saddle
fi'zi:k Antares R7
Seatpost
ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, length 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.35 mm | 1.31 mm | 1.31 mm |
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm | 300 mm |
| Stack | 605 mm | 609 mm | 618 mm | 632 mm |
| Reach | 432 mm | 451 mm | 470 mm | 484 mm |
| Top Tube Length | 597 mm | 618 mm | 639 mm | 657 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 390 mm | 420 mm | 470 mm | 510 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 85 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1114 mm | 1135 mm | 1157 mm | 1177 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Podium Carbon completes the Mondraker Podium model. 12 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
Mondraker Podium Carbon 2021 bike is equipped with the RockShox SID SL Select fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
Podium Carbon has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
The wheels on Podium Carbon are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Podium Carbon comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Mondraker Podium Carbon bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
