Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset RED eTap -
Suspension Rigid -
Drivetrain Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Titanium
Suspension Fork
MOOTS FLAT MOUNT DISC ROAD CARBON (BLACK)
Drivetrain
Rear Derailleur
SRAM RED AXS 2X 10-33 CASSETTE
Shift Levers
SRAM RED AXS 2X 10-33 CASSETTE
Crank
SRAM RED AXS 48/35 (170, 172.5, 175)
Bottom Bracket
SRAM DUB THREADED
Wheels
Rims
ENVE FOUNDATION 45 DISC CL - BLACK
Tires
VITTORIA CORSA CONTROL TLR - BLACK, 700x30
Brakes
Brakes
SRAM RED AXS HRD FLAT MOUNT 160/140 CL ROTORS
Cockpit
Stem
N/A
Handlebar
ENVE ROAD HANDLEBAR - COMPACT
Headset
CHRIS KING I8 (ASSORTED COLORS)
Seat
Saddle
SELLE ITALIA SLR BOOST TM MANGANESE
Seatpost
MOOTS CINCH POST
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 55cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.46 mm | 1.46 mm | 1.51 mm | 1.53 mm | 1.54 mm | 1.54 mm | 1.59 mm | 1.62 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 261 mm | 261 mm | 261 mm | 261 mm | 263 mm | 265 mm | 266 mm |
| Rake | 50 mm | 50 mm | 50 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Stack | 542 mm | 544 mm | 553 mm | 574 mm | 584 mm | 594 mm | 602 mm | 620 mm | 638 mm |
| Reach | 366 mm | 373 mm | 378 mm | 379 mm | 382 mm | 386 mm | 391 mm | 389 mm | 394 mm |
| Top Tube Length | 514 mm | 524 mm | 534 mm | 544 mm | 554 mm | 564 mm | 574 mm | 584 mm | 594 mm |
| Seat Tube Angle | 74.75 ° | 74.5 ° | 74.25 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 470 mm | 485 mm | 500 mm | 510 mm | 520 mm | 535 mm | 550 mm | 570 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 72.25 ° | 72.75 ° | 73 ° | 73 ° | 73.25 ° | 73.25 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 150 mm | 160 mm | 170 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 419 mm | 419 mm | 419 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 75 mm | 75 mm | 75 mm | 75 mm | 73 mm | 71 mm | 70 mm |
| Standover Height | 725 mm | 736 mm | 753 mm | 769 mm | 779 mm | 786 mm | 799 mm | 817 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Vamoots DR SRAM RED AXS is part of the Moots Vamoots model. There are 74 bikes that carry this model name. Take a sneak peek at all Moots Vamoots bikes models from 2022, by clicking here.
Model range prices
Moots Vamoots DR SHIMANO ULTEGRA Di2 2022 is the most economical model, with a starting price of 10619$. Moots Vamoots Disc RSL SHIMANO DURA ACE Di2 2022 on the other hand costs 13329$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Moots released this model in 2022, its price was 12123$. If we compare this with the average Endurance bike cost we notice that the price is 416.75% more expensive.
Vamoots DR SRAM RED AXS components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Moots Vamoots DR SRAM RED AXS 2022, has a 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Vamoots DR SRAM RED AXS has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
