Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 145mm -
Fork RockShox Lyrik
-
Groupset GX -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Lyrik RCT 3
Rear Shock
RockShox Monarch Plus RC3 DB
Drivetrain
Rear Derailleur
SRAM GX
Front Derailleur
N/A
Shift Levers
SRAM GX, 11-speed
Cassette
SRAM XG-1150, 10 x 42 tooth, 11-speed
Crank
Hope, 170mm length
Bottom Bracket
Hope, 73mm BSA
Chain
SRAM PC X1
Chain Guide
Hope Slick
Pedals
None included
Wheels
Front Hub
Hope Pro 4 Evo, Boost
Rear Hub
Hope Pro 4 Evo, Boost
Rims
Hope Tech Enduro
Spokes
Hope Tech Enduro
Tires
Front: Continental Baron Project Protection Apex, 2.4", Rear: Continental MountainKing 2 Protection, 2,4"
Brakes
Brakes
SRAM Guide R with 200mm front/180mm rear rotors
Brake Levers
SRAM Guide R
Cockpit
Stem
Hope AM, 35mm length
Handlebar
Renthal Fatbar, carbon, gold, 780 width
Grips
Ergon GE1, slim
Headset
Reset Flatstack A4
Seat
Saddle
Ergon SME 3-S
Seatpost
RockShox Reverb Stealth, 170 mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | MD High | LG High | XL High | XXL High |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.26 mm | 1.22 mm | 1.19 mm | 1.18 mm |
| Bottom Bracket Height | 352 mm | 352 mm | 352 mm | 352 mm | 352 mm |
| Front Center | 807 mm | 836 mm | 866 mm | 891 mm | 919 mm |
| Rake | 56 mm | 55 mm | 56 mm | 56 mm | 56 mm |
| Trail | 117 mm | 118 mm | 117 mm | 117 mm | 117 mm |
| Stack | 621 mm | 621 mm | 630 mm | 640 mm | 658 mm |
| Reach | 463 mm | 493 mm | 518 mm | 538 mm | 558 mm |
| Top Tube Length | 609 mm | 639 mm | 665 mm | 689 mm | 713 mm |
| Seat Tube Angle | 77.2 ° | 77.2 ° | 77.2 ° | 77.2 ° | 77.2 ° |
| Seat Tube Length | 420 mm | 450 mm | 470 mm | 500 mm | 520 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 130 mm | 150 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 454 mm | 460 mm |
| Wheelbase | 1254 mm | 1283 mm | 1313 mm | 1344 mm | 1378 mm |
| Bottom Bracket Drop | 22 mm | 22 mm | 22 mm | 22 mm | 22 mm |
| Standover Height | 719 mm | 747 mm | 766 mm | 794 mm | 814 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Ion-G15 Techline is part of the Nicolai Ion G15 model. 2 bikes variations carry this model name so far. Take a sneak peek at all Nicolai Ion G15 bikes models from 2018, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
a bit heavier than average, Ion-G15 Techline has a weight of 14 kg (30.86 lbs). In conclusion, the average Trail bike weighs 7.86% less than Ion-G15 Techline.
Overview of components
Fork
The RockShox Lyrik is included from the factory. It has a travel distance of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Ion-G15 Techline has a rear shock with a travel of 145mm. The model RockShox Monarch Plus RC3 DB is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Ion-G15 Techline are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Nicolai Ion-G15 Techline has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
