Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 155mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Racing Shox 36 Float Factory FIT, HSC/LSC, Boost axle
Rear Shock
FOX Racing Float X2 Factory, Comp-lever, 216mm x 63mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 12-speed
Cassette
SRAM XG 1295 Eagle, 12-speed, 10-50 tooth
Crank
SRAM X01 Eagle, 170mm length
Bottom Bracket
SRAM Team BSA GXP
Chain
SRAM CN-X-01 Eagle, 12-speed
Chain Guide
Universal Transmission Bio-Bike, upper guide with lower bashguard
Pedals
N/A
Wheels
Front Hub
DT Swiss EX 1501
Rear Hub
DT Swiss EX 1501
Rims
DT Swiss EX 1501, 30mm
Spokes
DT Swiss EX 1501
Tires
Front: Continental Der Baron, Project ProTection Apex, 27.5" x 2.4", Rear: Continental Mountain King II, ProTection, 27.5" x 2.4"
Brakes
Brakes
Magura MT7, 203mm front rotor, 180mm rear rotor
Brake Levers
Magura MT7, HC
Cockpit
Stem
Nicolai MTB, 35mm
Handlebar
Renthal Fatbar Carbon, 780mm width, 20mm rise
Grips
Ergon GE1 Slim, black
Headset
Cane Creek Forty
Seat
Saddle
Ergon SMA30 Comp, Stealth
Seatpost
Bikeyoke Revive 2.0 dropper, 160mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.23 mm | 1.21 mm | 1.19 mm | 1.18 mm | 1.17 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 826 mm | 846 mm | 868 mm | 893 mm | 916 mm |
| Rake | 45 mm | 44 mm | 44 mm | 46 mm | 41 mm |
| Trail | 127 mm | 128 mm | 128 mm | 126 mm | 131 mm |
| Stack | 602 mm | 611 mm | 620 mm | 636 mm | 653 mm |
| Reach | 488 mm | 505 mm | 523 mm | 538 mm | 558 mm |
| Top Tube Length | 624 mm | 646 mm | 665 mm | 684 mm | 708 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 420 mm | 450 mm | 470 mm | 500 mm | 520 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 452 mm | 457 mm |
| Wheelbase | 1271 mm | 1292 mm | 1314 mm | 1345 mm | 1373 mm |
| Bottom Bracket Drop | 17 mm | 17 mm | 17 mm | 17 mm | 17 mm |
| Standover Height | 711 mm | 743 mm | 763 mm | 791 mm | 813 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
About this model
Ion G16 Qlfline is part of the Nicolai Ion model. There are 4 bikes that carry this model name. Take a sneak peek at all Nicolai Ion bikes models from 2018, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Enduro bikes
On a deeper look, we notice that the average weight of an Enduro bike is 14.27 kg (31.46 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 14.2 kg (31.31 lbs), the Ion G16 Qlfline model is slightly lighter than average. In other words, this model is 0.49% lighter than the average Enduro bike.
Overview of components
Fork
This bike has the Fox Factory Float 36 fork installed. The fork’s travel is 170mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Ion G16 Qlfline has a rear shock with a travel of 155mm. The model FOX Racing Float X2 Factory is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The Ion G16 Qlfline 2018 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
