Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 203mm -
Travel Rear 227mm -
Fork Marzocchi
-
Groupset Saint -
Suspension Full -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Hydraformed AL, adjustable travel, 199mm-227mm travel, adjustable headtube angle, bb height, 1.5” forged headtube
Suspension Fork
Marzocchi 888 RCV, 203 mm of travel, 1-1/8” steer tube
Rear Shock
Fox DHX-3 w/ factory tuned ProPedal
Drivetrain
Rear Derailleur
Shimano Saint, 9 speed, medium cage
Shift Levers
Shimano Saint rapid fire
Cassette
Shimano LX , 9 speed, 11-32T
Crank
Race Face Evolver DH or Shimano Saint, 170 mm 36T, E-13 SRS Guard with Translucent Red guard
Bottom Bracket
Shimano Saint
Chain
Shimano CN-HG-53, 9 speed
Pedals
Flat pedal with sealed bearing, steel pins, grey
Wheels
Front Hub
Shimano Saint, 20mm axle
Rear Hub
Shimano Saint, 150 x 12mm, 9 spd
Rims
WTB Laser Disc FR 30 mm, 32 H, Grey
Spokes
Stainless steel, black 2.0
Tires
WTB Dissent 26 x 2.5, high grip compound, DH casing
Brakes
Brakes
Shimano Saint, 8” rotor
Brake Levers
Shimano Saint
Cockpit
Stem
Marzocchi clamp on direct mount 53 mm / 63 mm extension
Handlebar
Truvativ Hussefelt 710 mm x 25mm rise, 31.8mm, Grey
Grips
Pro Palm lock on grip
Headset
FSA Orbit E 1.5” R reducer internal 1.5” to 1-1/8”
Seat
Saddle
WTB Silverado custom cover, chromoly rails
Seatpost
Truvativ XR double bolt, 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 360 mm | 360 mm | 360 mm |
| Front Center | 710 mm | 725 mm | 751 mm |
| Top Tube Length | 572 mm | 592 mm | 617 mm |
| Seat Tube Angle | 71.3 ° | 71.3 ° | 71.3 ° |
| Seat Tube Length | 419 mm | 432 mm | 445 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 125 mm | 125 mm | 125 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1157 mm | 1172 mm | 1197 mm |
| Bottom Bracket Drop | -17 mm | -17 mm | -17 mm |
| Standover Height | 760 mm | 757 mm | 758 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
’09 A-line Park belongs to the Norco 09 model. 13 bikes variations carry this model name so far. You can easily view all of the Norco 09 bikes models from 2010, here.
Model range prices
The most economical model, the Norco ’09 VFR D-2 2010 has a starting price of 1239$. Norco ’09 Shore One 2010 on the other hand is the most expensive at 4850$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Downhill bikes
If you want to purchase a solid Downhill bike, it is important to know that the average cost is 3391$. However, this doesn’t mean that if you spend less money on a Downhill bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2010 and its price was 4350$. If we compare this with the average Downhill bike cost we notice that the price is 28.28% more expensive.
’09 A-line Park components
Fork
This bike has the Marzocchi fork installed. The fork’s travel is 203mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is Fox DHX-3 w/ factory tuned ProPedal, with a travel distance of 227mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the ’09 A-line Park bike is equipped with the 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco ’09 A-line Park is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
