Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset NX Eagle, Truvativ Stylo -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Double Butted X6 Aluminum
Suspension Fork
Norco Carbon Fat Fork
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle, 12 speed
Cassette
SRAM PG1230 Eagle, 11-50T
Crank
Truvativ Stylo 6K Eagle, DUB FAT5, 30T
Bottom Bracket
DUB, 100mm threaded
Chain
SRAM NX Eagle
Pedals
VP Flat, Nylon
Wheels
Front Hub
KT M9CF, Sealed, 15x150mm
Rear Hub
KT-M9CR, 12x197mm
Rims
SB-T80 TR 26" 32H
Tires
Terrene Johnnny 5, 26x5.0”
Brakes
Brakes
SRAM Level, Hydraulic, 180mm
Cockpit
Stem
Norco 6061 Alloy, 60mm, 35mm bore
Handlebar
Norco 6061 DB Alloy, 780mm
Grips
VP lock on
Headset
FSA Internal
Seat
Saddle
Fizik Taiga
Seatpost
X-Fusion Manic dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.32 mm | 1.26 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 328 mm | 328 mm |
| Front Center | 684 mm | 718 mm | 751 mm | 784 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 94 mm | 94 mm | 94 mm | 94 mm |
| Stack | 596 mm | 605 mm | 614 mm | 624 mm |
| Reach | 405 mm | 435 mm | 465 mm | 495 mm |
| Top Tube Length | 577 mm | 610 mm | 643 mm | 675 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 395 mm | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1114 mm | 1148 mm | 1181 mm | 1215 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 658 mm | 659 mm | 678 mm | 698 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Bigfoot 1 is part of the Norco Bigfoot model. Norco released 34 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Norco Bigfoot 3 2020 is the most affordable bike of this model and has a price of 1099$. On the other hand, Norco Bigfoot 1 Suspension 2020, is the most expensive and costs 2599$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fatbike bikes
According to our calculations, the average cost of a Fatbike bike that is reliable is 1743$. However, even though the average price of a Fatbike bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1999$. Doing a quick comparison, we notice that Bigfoot 1 price is 14.69% higher than the average cost of a Fatbike bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the Bigfoot 1 model has 26″ aluminum wheels. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Bigfoot 1 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Norco Bigfoot 1 comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
