Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset NX -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Bigfoot, Aluminum, 9x190mm QR Dropouts
Suspension Fork
Norco 6061 Aluminum Fat Fork, 15x150mm TA, 51mm Offset
Drivetrain
Rear Derailleur
SRAM NX, 11 Speed
Front Derailleur
-
Shift Levers
Rear: SRAM NX, 11 Speed, Front: -
Cassette
SRAM NX PG-1130, 11-42T, 11 Speed
Crank
Samox Alloy, 170mm (S) | 175mm (M/L/XL), 28T
Bottom Bracket
External, Threaded BSA 100mm
Chain
SRAM NX PC-1110, 11 Speed
Pedals
VP Nylon Flat Pedals, 9/16"
Wheels
Front Hub
KT M9CF 150x15 Sealed Hub
Rear Hub
Joytech D102TSE, 10x190mm QR
Rims
Alloy SW, 32 Hole, 80mm Internal Width
Tires
CY H-5176, 26x4.9”
Brakes
Brakes
Tektro MD-M280, 2 Piston Mechanical Disc, 180mm Rotor
Brake Levers
Tektro Alloy
Cockpit
Stem
Alloy 60mm x 31.8
Handlebar
X6 Alloy 750mm x 31.8
Grips
VP, Lock-On
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco XC Saddle
Seatpost
Norco Alloy, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.41 mm | 1.36 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 682 mm | 708 mm | 733 mm | 759 mm |
| Rake | 52 mm | 51 mm | 51 mm | 51 mm |
| Trail | 84 mm | 86 mm | 86 mm | 86 mm |
| Stack | 598 mm | 608 mm | 617 mm | 627 mm |
| Reach | 393 mm | 415 mm | 438 mm | 460 mm |
| Top Tube Length | 593 mm | 618 mm | 643 mm | 668 mm |
| Seat Tube Angle | 71.7 ° | 71.7 ° | 71.7 ° | 71.7 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1125 mm | 1151 mm | 1177 mm | 1203 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 731 mm | 739 mm | 752 mm | 745 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Bigfoot 2 belongs to the Norco Bigfoot model. 34 bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
The most economical model, the Norco Bigfoot 2 2019 has a starting price of 1099$. Norco Bigfoot 1 2019 on the other hand is the most expensive at 1599$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fatbike bikes
If you want to purchase a solid Fatbike bike, it is important to know that the average cost is 1743$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fatbike bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2019 for 1099$. Comparing the average cost of a Fatbike bike to this one, you will see that Bigfoot 2 price is 58.6% lower.
Bigfoot 2 components
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
As for the wheels, Norco Bigfoot 2 2019, has a 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Bigfoot 2 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
