Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Cabot Double Butted Chromo w/C-Stay Disc
Suspension Fork
Cabot Touring Chromoly w/Disc Mount
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105 RD-5701-GS - Silver
Front Derailleur
Shimano 105 FD-5703 - Silver
Shift Levers
Shift cable casing - Grey
Cassette
Shimano Tiagra CS-4600 12-30T 10spd
Crank
Shimano FC-R563 50/39/30 - Silver
Bottom Bracket
Shimano SM-BB4600
Chain
Shimano Tiagra CN-4601
Chain Tensioner
N/A
Pedals
Alloy Body/Alloy Cage - Silver
Wheels
Front Hub
Shimano HB-R505 Disc 36H - Silver
Rear Hub
Shimano FH-R505 Disc 36H - Silver
Rims
Freedom Ryder 23 700c 36hole - Silver
Tires
Continental CityRIDE 32c - Reflex w/ProTection
Brakes
Brakes
Tektro CR710 Canti - Silver
Brake Levers
Shimano 105 ST-5703 - Silver
Disk Rotors
N/A
Cockpit
Stem
Norco High Rise 35degree - Silver
Handlebar
Ritchey BioMax - Silver
Grips
Shockproof Wrap - Black
Headset
FSA Orbit DL - Silver
Seat
Saddle
Norco Gel Vacuum w/Chromo Rail - Black
Seatpost
Norco Alloy 27.2mm - Silver
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.55 mm | 1.59 mm | 1.64 mm | 1.68 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm | 277 mm |
| Front Center | 596 mm | 602 mm | 608 mm | 612 mm | 616 mm |
| Rake | 52 mm | 52 mm | 52 mm | 51 mm | 52 mm |
| Trail | 64 mm | 61 mm | 58 mm | 56 mm | 51 mm |
| Stack | 542 mm | 563 mm | 584 mm | 605 mm | 626 mm |
| Reach | 359 mm | 363 mm | 367 mm | 370 mm | 372 mm |
| Top Tube Length | 512 mm | 527 mm | 542 mm | 557 mm | 572 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1028 mm | 1034 mm | 1040 mm | 1044 mm | 1048 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 738 mm | 761 mm | 783 mm | 806 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Cabot 1 completes the Norco Cabot model. There are 7 bikes that carry this model name. Check out the entire range from 2014 of this model, by clicking this link.
Model range prices
Norco Cabot 2 2014 is the most affordable bike of this model and has a price of 860$. On the other hand, Norco Cabot 1 2014, is the most expensive and costs 1215$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Touring bikes
Our math shows that the average cost of a dependable Touring bike is 1007$. However, even though the average price of a Touring bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Norco released this model in 2014, its price was 1215$. Comparing the average cost of a Touring bike to this one, you will see that Cabot 1 price is 20.66% higher.
Overview of components
Fork material
The fork on this bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
When leaving the production line, the Cabot 1 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Cabot 1 comes with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
