Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy Gold RL
-
Groupset NX, Suntour SR -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Charger 6061 Alloy XC Frame w/DB TT & DT
Suspension Fork
Rock Shox Judy Gold RL 100mm Boost
Drivetrain
Rear Derailleur
SRAM NX 11spd
Shift Levers
SRAM NX 11spd
Cassette
SRAM PG-1130 11/42 Cassette
Crank
SR Suntour Zeron 30T
Bottom Bracket
SR Suntour BB24
Chain
SRAM PC-1110 11spd
Pedals
Alloy Pedals
Wheels
Front Hub
Novatec Boost 110mm x 15mm
Rear Hub
Joytech D342TSE-HL Alloy Disc QR 9spd
Rims
WTB MX21 29"/27.5" DW Rims
Tires
WTB Nineline 29"x 2.25/Beeline 27.5" x 2.25
Brakes
Brakes
SRAM Level 180mm
Brake Levers
SRAM Level
Cockpit
Stem
Alloy 60mm/70mm x 31.8
Handlebar
X6 Alloy 750mm x 31.8
Grips
Norco Grip
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco XC Saddle
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.45 mm | 1.4 mm | 1.36 mm |
| Bottom Bracket Height | 303 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 667 mm | 690 mm | 713 mm | 736 mm |
| Rake | 48 mm | 51 mm | 51 mm | 51 mm |
| Trail | 87 mm | 82 mm | 80 mm | 79 mm |
| Stack | 618 mm | 618 mm | 629 mm | 639 mm |
| Reach | 401 mm | 426 mm | 448 mm | 469 mm |
| Top Tube Length | 586 mm | 616 mm | 646 mm | 676 mm |
| Seat Tube Angle | 73.4 ° | 73 ° | 72.6 ° | 72.2 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 69.75 ° | 70 ° | 70.25 ° | 70.5 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1099 mm | 1124 mm | 1147 mm | 1169 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 726 mm | 771 mm | 780 mm | 791 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Charger 1 29 is part of the Norco Charger model. Norco released 83 bikes variations of this model so far. Take a sneak peek at all Norco Charger bikes models from 2018, by clicking here.
Model range prices
Norco Charger 2.1 2018 is the cheapest bike model and costs 679$. Norco Charger 1 Womens 29 2018 is the most expensive one and costs 1149$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Norco Charger 1 29 price was 1149$. In conclusion, this bike price is 65.8% smaller than the price of the average Crosscountry bike.
Charger 1 29 components
Fork
This bike has the RockShox Judy Gold RL fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The Charger 1 29 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Charger 1 29 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Norco Charger 1 29 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
