Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Acera, FSA -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Charger Alloy XC Frame W/Formed Tubing
Suspension Fork
Suntour XCM 26" 100mm w/Hydraulic lock-out
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera RD-M390 9spd
Front Derailleur
Shimano Acera FD-M390 3spd
Shift Levers
Jagwire
Cassette
Shimano CS-HG20 11/34 9spd
Crank
FSA Dyna Drive 44/32/22T - Black
Bottom Bracket
FSA BB-7420ST Cartridge
Chain
SRAM PG951 9spd
Chain Tensioner
N/A
Pedals
Wellgo Resin Pedals
Wheels
Front Hub
Shimano HB-RM35 CenterLock Disc
Rear Hub
Shimano FH-RM35 CenterLock Disc
Rims
WTB SX19 26" 32H DW
Tires
Geax AKA 2.2
Brakes
Brakes
Shimano BR-M375 Mech Disc 160mm
Brake Levers
Tektro Alloy
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy
Handlebar
Norco Alloy 15mm Riser
Grips
T-One H2O Grips
Headset
FSA No. 10 w/16mm conical spacer
Seat
Saddle
Norco XC Saddle
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.46 mm | 1.5 mm | 1.44 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm | 302 mm |
| Front Center | 603 mm | 608 mm | 624 mm | 639 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm |
| Stack | 551 mm | 553 mm | 578 mm | 578 mm |
| Reach | 369 mm | 379 mm | 386 mm | 401 mm |
| Top Tube Length | 528 mm | 543 mm | 558 mm | 573 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 330 mm | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1024 mm | 1029 mm | 1045 mm | 1060 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 33 mm |
| Wheels | 24" | 24" | 24" | 24" |
Model Overview
Charger 6.3 Forma completes the Norco Charger model. Norco released 83 bikes variations of this model so far. Take a sneak peek at all Norco Charger bikes models from 2013, by clicking here.
Model range prices
The most economical model, the Norco Charger 6.3 Forma 2013 has a starting price of 690$. Norco Charger 9.1 2013 on the other hand is the most expensive at 1045$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Mountain bikes
According to our math, the average price for a trustworthy Mountain bike is 616$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Norco released this model in 2013, its price was 690$. Doing a quick comparison, we notice that Charger 6.3 Forma price is 12.01% more expensive than the average cost of a Mountain bike.
Overview of components
Fork
This bike has the SunTour XCM fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Norco Charger 6.3 Forma 2013, has a 24″ aluminum model. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
