Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Gold RL
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Charger 29" DB Alloy XC Frame
Suspension Fork
Rock Shox Recon Gold TK 100mm/15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT 10spd Shadow
Front Derailleur
Shimano Deore 2spd
Shift Levers
Jagwire
Cassette
Shimano Deore HG50 11-36T 10spd
Crank
Shimano Deore FC-617 36/22
Bottom Bracket
Shimano GXP
Chain
KMC X10 10spd
Chain Tensioner
N/A
Pedals
Wellgo Alloy Pedals
Wheels
Front Hub
Norco Alloy 15mm
Rear Hub
Shimano Deore FHM475 10spd
Rims
Alex MD19 DW 29"
Tires
N/A
Brakes
Brakes
Shimano M445 Hydraulic 160mm
Brake Levers
Shimano Deore M445
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy 60mm
Handlebar
Norco Lite DB 720mm Flat Bar
Grips
Norco Grip
Headset
Feimin Sealed Internal H/S
Seat
Saddle
Norco XC Saddle
Seatpost
Norco Alloy 31.6/400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.53 mm | 1.44 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 303 mm | 303 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 644 mm | 667 mm | 690 mm | 713 mm | 736 mm |
| Rake | 50 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 87 mm | 84 mm | 82 mm | 80 mm | 79 mm |
| Stack | 628 mm | 629 mm | 629 mm | 640 mm | 650 |
| Reach | 387 mm | 412 mm | 437 mm | 459 mm | 480 mm |
| Top Tube Length | 567 mm | 597 mm | 627 mm | 657 mm | 687 mm |
| Seat Tube Angle | 73.8 ° | 73.4 ° | 73 ° | 72.6 ° | 72.2 ° |
| Seat Tube Length | 390 mm | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 69.5 ° | 69.75 ° | 70 ° | 70.25 ° | 70.5 ° |
| Head Tube Length | 100 mm | 100 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1087 mm | 1110 mm | 1135 mm | 1158 mm | 1180 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 731 mm | 737 mm | 782 mm | 791 mm | 802 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Charger 9.1 belongs to the Norco Charger model. 83 bikes variations carry this model name so far. You can easily view all of the Norco Charger bikes models from 2016, here.
Model range prices
Norco Charger 9.3 2016 is the cheapest bike model and costs 895$. Norco Charger 7.0 2016 is the most expensive one and costs 1800$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Norco Charger 9.1 price was 1380$. If we compare this with the average Crosscountry bike cost we notice that the price is 38.04% lower.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Gold RL model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the Charger 9.1 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Charger 9.1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Charger 9.1 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
