Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset X5, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Charger 6061 Alloy XC W/Formed Tubing
Suspension Fork
RockShox XC 30 TK 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X5 10spd
Front Derailleur
Shimano Deore
Shift Levers
Jagwire
Cassette
SRAM PG1030 11/36
Crank
FSA Gamma Drive 42/32/24
Bottom Bracket
FSA Mega Exo
Chain
SRAM PG1031 10spd
Chain Tensioner
N/A
Pedals
Wellgo Alloy Pedals
Wheels
Front Hub
SRAM MTH-406
Rear Hub
SRAM MTH-406
Rims
Alex TD26 D/W
Tires
Schwalbe Rapid Rob 29" x 2.10 tires"
Brakes
Brakes
Shimano M445 Hydraulic 160mm
Brake Levers
Shimano Deore M445
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy
Handlebar
Norco Alloy 15mm Riser 680mm
Grips
Norco Grip
Headset
FSA No. 10 w/16mm conical spacer
Seat
Saddle
Norco XC Forma Saddle
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 18.5" |
|---|---|---|---|
| Stack Reach Ratio | 1.71 mm | 1.68 mm | 1.59 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 307 mm |
| Front Center | 620 mm | 629 mm | 650 |
| Rake | 55 mm | 56 mm | 56 mm |
| Trail | 78 mm | 73 mm | 73 mm |
| Stack | 622 mm | 629 mm | 629 mm |
| Reach | 363 mm | 375 mm | 395 mm |
| Top Tube Length | 548 mm | 568 mm | 588 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1059 mm | 1068 mm | 1091 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 63 mm |
| Standover Height | 778 mm | 768 mm | 766 mm |
| Front Travel | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
Charger 9.2 Forma completes the Norco Charger model. Norco released 83 bikes variations of this model so far. You can get a glimpse at all models from 2014, by clicking on this link.
Model range prices
The most economical model, the Norco Charger 20 2014 has a starting price of 549$. Norco Charger 7.1 2014 on the other hand is the most expensive at 1375$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1045$. Comparing this to the average Crosscountry bike price, we see that the price is 82.3% lower.
Charger 9.2 Forma components
Fork
This bike has the RockShox 30 Silver TK fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The Charger 9.2 Forma 2014 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Charger 9.2 Forma comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
