Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Charger 6061 Alloy XC W/Formed Tubing
Suspension Fork
Rock Shox XC30 TK 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Alivio RD-M430 9spd
Front Derailleur
Shimano Altus 3spd
Shift Levers
Jagwire
Cassette
Shimano CS-HG20 11/34 9spd
Crank
Shimano Acera 44/32/22
Bottom Bracket
Shimano Octalink
Chain
SRAM PG951 9spd
Chain Tensioner
N/A
Pedals
Wellgo Resin Pedals
Wheels
Front Hub
SRAM MTH-306
Rear Hub
SRAM MTH-306
Rims
Alex TD26 D/W
Tires
Schwalbe Rapid Rob 29" x 2.10 tires"
Brakes
Brakes
Shimano M395 Hydraulic 160mm
Brake Levers
Shimano Deore BL-M395
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy
Handlebar
Norco Alloy 10mm riser 700mm
Grips
Norco Grip
Headset
FSA No. 10 w/16mm conical spacer
Seat
Saddle
Norco XC Saddle
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 18.5" | 20" | 21.5" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.71 mm | 1.68 mm | 1.59 mm | 1.53 mm | 1.5 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 620 mm | 629 mm | 650 | 670 mm | 684 mm |
| Rake | 55 mm | 56 mm | 56 mm | 55 mm | 55 mm |
| Stack | 622 mm | 629 mm | 629 mm | 634 mm | 639 mm |
| Reach | 363 mm | 375 mm | 395 mm | 414 mm | 426 mm |
| Top Tube Length | 548 mm | 568 mm | 588 mm | 608 mm | 628 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm | 508 mm | 546 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm | 120 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1059 mm | 1068 mm | 1091 mm | 1111 mm | 1125 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 778 mm | 768 mm | 766 mm | 764 mm | 778 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 24" | 24" | 24" | 24" | 24" |
About this model
Charger 9.3 is a Norco Charger model. Norco launched 83 bikes of this model so far. Take a sneak peek at all Norco Charger bikes models from 2014, by clicking here.
Model range prices
Norco Charger 20 2014 is the most affordable bike of this model and has a price of 549$. On the other hand, Norco Charger 7.1 2014, is the most expensive and costs 1375$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Mountain bikes average price
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, this doesn’t mean that if you spend less money on a Mountain bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2014 for 820$. In conclusion, this bike price is 33.12% higher than the price of the average Mountain bike.
Overview of components
Wheels size
When it comes to wheels, the Charger 9.3 bike is equipped with the 24″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Charger 9.3 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
