Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 alloy w/comfort stays & internal cables
Suspension Fork
SR Suntour NEX-26' 63mm travel fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus RD-M310
Front Derailleur
Shimano Tourney FD-M191
Shift Levers
N/A
Cassette
Shimano CS-HG31 11-32T 8 speed
Crank
Shimano Altus FC-M171C 48/38/28
Bottom Bracket
Cartridge BB
Chain
KMC Z-72
Chain Tensioner
N/A
Pedals
Wellgo Alloy Comfort Pedal w/ Kraton
Wheels
Front Hub
Joytech Alloy hub 32h - Silver
Rear Hub
Joytech Alloy hub w/Cassette 32h - Silver
Rims
Double wall alloy w/CNC side wall 32h - Silver
Tires
Chaoyang H-460 26 x 1.95
Brakes
Brakes
Tektro 837AL V-Brakes
Brake Levers
Shimano Easy-Fire 51 w/4 finger lever
Disk Rotors
N/A
Cockpit
Stem
Forged alloy adjustable stem
Handlebar
Alloy comfort high riser bar
Grips
Ergonomic w/Norco logo bar plug
Headset
Semi-Integrated threaded
Seat
Saddle
Selle Royal Loire Saddle
Seatpost
Alloy suspension seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.68 mm | 1.62 mm | 1.56 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm |
| Front Center | 626 mm | 642 mm | 657 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 82 mm | 82 mm | 82 mm |
| Stack | 616 mm | 616 mm | 616 mm |
| Reach | 366 mm | 381 mm | 396 mm |
| Top Tube Length | 606 mm | 621 mm | 636 mm |
| Seat Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Seat Tube Length | 355 mm | 415 mm | 475 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 170 mm | 170 mm | 170 mm |
| Chainstay Length | 476 mm | 476 mm | 476 mm |
| Wheelbase | 1099 mm | 1114 mm | 1129 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Standover Height | 533 mm | 512 mm | 497 mm |
| Front Travel | 63 mm | 63 mm | 63 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Citadel Step-Thru completes the Norco Citadel model. 22 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Norco Citadel 2017 is the most economical model, with a starting price of 529$. Norco Citadel Step-Thru 2017 on the other hand costs 529$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid bikes
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 529$. Comparing this to the average Hybrid bike price, we see that the price is 6.24% lower.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Citadel Step-Thru components
Fork
The fork installed on this bike is the SunTour NEX model. The travel on this model is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on Citadel Step-Thru are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Citadel Step-Thru comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
