Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, Tiagra -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FBR Flat Bar Double Butted Alloy
Suspension Fork
Aerodynamic Alloy
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Sora RD-3500 SS - Black
Front Derailleur
Shimano FD-R440 - Silver
Shift Levers
Shift cable casing - Dark Grey
Cassette
SRAM CS-PG-830 11-30T 8spd
Crank
FSA Tempo CK-200TT 50/34T - Black
Bottom Bracket
FSA BB-7420ST Cartridge
Chain
KMC 8 speed
Chain Tensioner
N/A
Pedals
Wellgo resin body w/steel cage
Wheels
Front Hub
Norco Sport Road 32h - Black
Rear Hub
Norco Sport Road 32h - Black
Rims
Double Wall alloy - Black
Tires
CST Road Tires 700x25c - Black
Brakes
Brakes
Tektro R317 - Black
Brake Levers
Shimano ST-R221 EZ Fire - Black
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/White
Handlebar
Norco Flat - Black w/White
Grips
Phorm Ergonomic Lock-On - Black
Headset
FSA Orbit CE - ACB Integrated headset
Seat
Saddle
Norco Sport - White
Seatpost
Norco - Black w/White
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - | - |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.42 mm | 1.44 mm | 1.46 mm | 1.48 mm |
| Bottom Bracket Height | 277.5 mm | 277.5 mm | 277.5 mm | 277.5 mm | 277.5 mm |
| Front Center | 610 mm | 620 mm | 632 mm | 647 mm | 655 mm |
| Rake | 45 mm | 44 mm | 46 mm | 45 mm | 45 mm |
| Trail | 73 mm | 70 mm | 65 mm | 66 mm | 63 mm |
| Stack | 549 mm | 570 mm | 591 mm | 610 mm | 631 mm |
| Reach | 392 mm | 401 mm | 409 mm | 418 mm | 426 mm |
| Top Tube Length | 539 mm | 559 mm | 579 mm | 599 mm | 619 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1025 mm | 1035 mm | 1047 mm | 1061 mm | 1071 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
FBR 3 belongs to the Norco Fbr model. Norco released 14 bikes variations of this model so far. Take a sneak peek at all Norco Fbr bikes models from 2013, by clicking here.
Model range prices
Norco FBR 3 2013 is the most economical model, with a starting price of 689$. Norco FBR 1 2013 on the other hand costs 1295$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Fitness bikes average price
If you want an acceptable Fitness bike you should know that the average price is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco FBR 3 price was 689$. Doing a quick comparison, we notice that FBR 3 price is 5.03% higher than the average cost of a Fitness bike.
Overview of components
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The FBR 3 2013 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The FBR 3 has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
