Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FBR Flat Bar Double Butted Alloy
Suspension Fork
Aerodynamic Alloy
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Sora RD-3500 SS - Black
Front Derailleur
Shimano Claris FD-2400
Shift Levers
Shift cable casing - Silver
Cassette
Shimano CS-HG31 11-30T 8spd
Crank
Shimano FC-2450 50/34T - Black
Bottom Bracket
FSA BB-7420ST Cartridge
Chain
KMC Z-72
Chain Tensioner
N/A
Pedals
Wellgo resin body w/steel cage
Wheels
Front Hub
Norco Sport Road 32h - Black
Rear Hub
Norco Sport Road 32h - Black
Rims
Double Wall alloy - Black
Tires
Continental Ultra Sport II - Black 700x25c
Brakes
Brakes
Tektro R315 - Black
Brake Levers
Shimano Claris ST-R240 - Silver
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/Blue
Handlebar
Norco Flat - Black w/Blue
Grips
Phorm Ergonomic Lock-On - Black
Headset
FSA Orbit CE - ACB Integrated headset
Seat
Saddle
Norco Sport Froma - White
Seatpost
Norco Alloy 27.2mm - Black w/Blue
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 48cm | 51cm |
|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.4 mm | 1.42 mm |
| Bottom Bracket Height | 277.5 mm | 277.5 mm | 277.5 mm |
| Front Center | 598.3 mm | 610 mm | 620 mm |
| Rake | 45 mm | 45 mm | 44 mm |
| Trail | 76 mm | 73 mm | 70 mm |
| Stack | 532 mm | 553 mm | 574 mm |
| Reach | 386 mm | 396 mm | 405 mm |
| Top Tube Length | 528 mm | 543 mm | 563 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1017 mm | 1029 mm | 1039 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm |
| Standover Height | 724 mm | 746 mm | 768 mm |
| Wheels | 700 | 700 | 700 |
Model Overview
FBR 3 Forma completes the Norco Fbr model. Norco released 14 bikes variations of this model so far. You can easily view all of the Norco Fbr bikes models from 2014, here.
Model range prices
Norco FBR 3 Forma 2014 is the most affordable bike of this model and has a price of 655$. On the other hand, Norco FBR 1 2014, is the most expensive and costs 1160$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Fitness bikes
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Norco FBR 3 Forma price was 655$. Comparing the average cost of a Fitness bike to this one, you will see that FBR 3 Forma price is 0.15% smaller.
FBR 3 Forma components
Fork material
FBR 3 Forma has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Norco FBR 3 Forma 2014, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco FBR 3 Forma is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
