Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 120mm -
Travel Rear 100mm -
Fork Manitou JUNIT Expert
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
20"
115cm - 129cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Frame, 100mm Travel, Tapered Head Tube
Suspension Fork
Manitou J-Unit Expert 20", Alloy Steerer, 120mm Travel
Rear Shock
Rock Shox Deluxe R, 170x30mm
Drivetrain
Rear Derailleur
SRAM GX Short Cage
Shift Levers
SRAM GX
Cassette
SRAM PG-1030, 11-36T, 10 Speed
Crank
Alloy 2 Piece, 28T Narrow Wide, 127mm
Bottom Bracket
BSA Threaded
Chain
KMC X10
Pedals
SDG Slater
Wheels
Front Hub
Bear Pawls, 15x110mm Boost, 6 Bolt
Rear Hub
Bear Pawls, 12x148mm, HG, 6 Bolt
Rims
Stan's Flow K 20", 28H
Tires
Front: Vee Flow Snap 2.4", Enduro Core, TR, Rear: Vee Flow Snap 2.4", Enduro Core, TR
Brakes
Brakes
Front: SRAM G2 R, Organic Pads, Rear: SRAM G2 R, Organic Pads
Brake Levers
SRAM G2 R
Cockpit
Stem
6061 Alloy, 35mm Rise, 31.8mm Clamp
Handlebar
SDG Slater, 640mm, 20mm Rise
Grips
SDG Slater
Headset
Sealed Cartridge Bearing, Tapered
Seat
Saddle
SDG Fly Jr.
Seatpost
TranzX YSP18B, 31.6mm, 100mm, Kid's Tune
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 20" |
|---|---|
| Stack Reach Ratio | 1.4 mm |
| Bottom Bracket Height | 270 mm |
| Front Center | 585 mm |
| Rake | 48 mm |
| Trail | 83 mm |
| Stack | 434 mm |
| Reach | 311 mm |
| Top Tube Length | 430 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 255 mm |
| Head Tube Angle | 64 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 346 mm |
| Wheelbase | 931 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 491 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 129 cm |
About this model
Fluid 1 FS 20 completes the Norco Fluid Fs model. There are 111 bikes that carry this model name. You can easily view all of the Norco Fluid Fs bikes models from 2022, here.
Model range prices
Norco Fluid 2 FS 20 2022 is the most economical model, with a starting price of 1999$. Norco Fluid FS 4.1 2022 on the other hand costs 2799$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Mountain bikes
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2699$. Doing a quick comparison, we notice that Fluid 1 FS 20 price is 338.15% higher than the average cost of a Mountain bike.
Fluid 1 FS 20 components
Fork
The fork installed on this bike is the Manitou JUNIT Expert model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
Fluid 1 FS 20 has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
As for the rear shock, this bike has the Rock Shox Deluxe R model, with a travel of 100mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
As for the wheels, Norco Fluid 1 FS 20 2022, has a 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid 1 FS 20 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike has one size only, so it might not fit you. In conclusion, double-check its size to make sure it’s a good fit for you.
Dropper post
Norco Fluid 1 FS 20 comes with a dropper post. Therefore, climbing or descending will be a breeze.
