Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 120mm -
Travel Rear 100mm -
Fork Manitou JUNIT Comp
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
20"
115cm - 129cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Frame, 100mm Travel, Tapered Head Tube
Suspension Fork
Manitou J-Unit Comp 20", Alloy Steerer, 120mm Travel
Rear Shock
X-Fusion 02 Pro R, 170x30mm
Drivetrain
Rear Derailleur
SRAM GX Short Cage
Shift Levers
SRAM GX
Cassette
SRAM PG-1030, 11-36T, 10 Speed
Crank
Alloy 2 Piece, 28T Narrow Wide, 127mm
Bottom Bracket
BSA Threaded
Chain
KMC X10
Pedals
VP-225 Jr. Flat
Wheels
Front Hub
Bear Pawls 15x110mm Boost, 6 Bolt
Rear Hub
Bear Pawls 12x148 Boost, HG, 6 Bolt
Rims
Stan's Flow K 20", 28H
Tires
Front: Vee Crown Gem 2.25", TR, Rear: Vee Crown Gem 2.25", TR
Brakes
Brakes
Front: Tektro HD-J285 Hydraulic, Organic Pads, Rear: Tektro HD-J285 Hydraulic, Organic Pads
Brake Levers
Tektro Hydraulic 2-Finger Jr.
Cockpit
Stem
6061 Alloy, 35mm Length, 31.8mm Clamp
Handlebar
6061 Aluminum, 660mm, 15mm Rise
Grips
Junior Lock-On
Headset
Sealed Cartridge Bearing, Tapered
Seat
Saddle
Norco Youth
Seatpost
6061 Aluminum, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 20" |
|---|---|
| Stack Reach Ratio | 1.4 mm |
| Bottom Bracket Height | 270 mm |
| Front Center | 285 mm |
| Rake | 40 mm |
| Trail | 83 mm |
| Stack | 434 mm |
| Reach | 311 mm |
| Top Tube Length | 430 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 255 mm |
| Head Tube Angle | 64 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 346 mm |
| Wheelbase | 631 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 491 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 129 cm |
About this model
Fluid 2 FS 20 is part of the Norco Fluid Fs model. 111 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Norco Fluid FS Youth 27.5 2023 is the most affordable bike of this model and has a price of 1655$. On the other hand, Norco Fluid FS A1 2023, is the most expensive and costs 3999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Mountain bikes average price
According to our math, the average price for a trustworthy Mountain bike is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2023 and its price was 1799$. Comparing this to the average Mountain bike price, we see that the price is 192.05% more expensive.
Fluid 2 FS 20 components
Fork
This bike has the Manitou JUNIT Comp fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
The Fluid 2 FS 20 has a rear shock with a travel of 100mm. The model X-Fusion 02 Pro R is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
As for the wheels, Norco Fluid 2 FS 20 2023, has a 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fluid 2 FS 20 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike has one size only, so it might not fit you. In conclusion, double-check its size to make sure it’s a good fit for you.
