Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset Deore, Suntour SR -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Fluid FS 24", Aluminum, 9x135mm QR Dropouts
Suspension Fork
RockShox 30 Silver TK 26 100mm solo air / alloy steer tube
Rear Shock
RockShox Monarch R HVI, 152x31mm, Custom light compression and rebound tune
Drivetrain
Rear Derailleur
Shimano Deore M615, SGS/Shadow Plus, 10 Speed
Shift Levers
Shimano Deore SL-M6000, 10 Speed
Cassette
SunRace CSMS2, 11-42T, 10 Speed
Crank
SR Suntour Zeron 2-Piece Aluminum, 152mm, Narrow/Wide Chainring 30T
Bottom Bracket
SR Suntour, Threaded BSA 73mm
Chain
KMC X10, 10 Speed
Chain Tensioner
Mr Control CH-MTS, Single Ring Chainguide
Pedals
Alloy Jr Flat Pedal black
Wheels
Front Hub
Joytech Q/R D041DSE
Rear Hub
Joy tech Q/R 10/11sp cass hub semi sealed
Rims
Alex MUS30, 32 Hole, 23.5mm Internal Width
Tires
Maxxis Minion DHF, 24x2.4"
Brakes
Brakes
Tektro HD-M286, Hydraulic Disc, 160mm Rotor
Brake Levers
Tektro HD-M286, Short Reach Levers
Cockpit
Stem
Short reach 35mm ext MTB stem
Handlebar
Norco 25mm rise 6061 DB alloy 680mm
Grips
Norco Gator
Headset
FSA # 10 internal 50 OD / 44 ID
Seat
Saddle
SDG Fly JR saddle
Seatpost
TranzX YSP19 Dropper, 80mm Travel, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.55 mm |
| Bottom Bracket Height | 312 mm |
| Front Center | 585 mm |
| Rake | 42 mm |
| Stack | 522 mm |
| Reach | 337 mm |
| Top Tube Length | 505 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 320 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 420 mm |
| Wheelbase | 1005 mm |
| Bottom Bracket Drop | 2 mm |
| Standover Height | 675 mm |
| Wheels | 24" |
About this model
Fluid 24 FS belongs to the Norco Fluid Fs model. There are 111 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Norco Fluid FS 4 Women’s 29 2019 is the cheapest bike model and costs 1649$. Norco Fluid FS 1 29 2019 is the most expensive one and costs 3049$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Mountain bikes
Our math shows that the average cost of a dependable Mountain bike is 616$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Mountain bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1749$. Doing a quick comparison, we notice that Fluid 24 FS price is 183.93% higher than the average cost of a Mountain bike.
Fluid 24 FS components
Fork
The fork installed on this bike is the RockShox 30 Silver TK model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Norco Fluid 24 FS 2019, has a 24″ aluminum model. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fluid 24 FS has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
The Norco model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
