Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" / 27.5" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset NX, Suntour SR -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid 6061 Alloy XC Frame w/DB TT & DT
Suspension Fork
SR Suntour XCM 32 DS 120mm/15mm
Drivetrain
Rear Derailleur
SRAM NX 11spd
Shift Levers
SRAM NX 11spd
Cassette
SRAM PG-1130 11/42 Cassette
Crank
SR Suntour Zeron Boost 30T
Bottom Bracket
SR Suntour BB24
Chain
SRAM PC-1110 11spd
Pedals
VP Nylon Flat Pedal
Wheels
Front Hub
Novatec Boost 110mm x 15mm
Rear Hub
Joytech Boost RR QR 32H
Rims
Alloy XD26 30mm 650B Plus 32H
Tires
WTB Ranger 27.5"x 2.8"
Brakes
Brakes
Tektro HD-M285 Hydraulic 160mm
Brake Levers
Tektro HD-M285
Cockpit
Stem
Alloy 60mm x 31.8
Handlebar
X6 Alloy 750mm x 31.8
Grips
Norco Grip
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco XC Saddle
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.49 mm | 1.44 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 655 mm | 681 mm | 716 mm | 742 mm | 768 mm |
| Rake | 42 mm | 43 mm | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 96 mm | 92 mm | 92 mm | 92 mm |
| Stack | 595 mm | 595 mm | 608 mm | 617 mm | 627 mm |
| Reach | 375 mm | 400 mm | 422 mm | 444 mm | 466 mm |
| Top Tube Length | 552 mm | 582 mm | 612 mm | 642 mm | 672 mm |
| Seat Tube Angle | 73.5 ° | 73.1 ° | 72.7 ° | 72.3 ° | 71.9 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 110 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 417 mm | 417 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1069 mm | 1095 mm | 1139 mm | 1165 mm | 1191 mm |
| Bottom Bracket Drop | 41 mm | 41 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 715 mm | 714 mm | 770 mm | 781 mm | 792 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 26" | 26" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Fluid 3 HT is part of the Norco Fluid Ht model. Norco launched 78 bikes of this model so far. You can easily view all of the Norco Fluid Ht bikes models from 2018, here.
Model range prices
Norco Fluid HT 3 Womens 26 2018 is the most affordable bike of this model and has a price of 899$. On the other hand, Norco Fluid 1 HT Womens 2018, is the most expensive and costs 1749$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Norco Fluid 3 HT price was 899$. Doing a quick comparison, we notice that Fluid 3 HT price is 207.23% smaller than the average cost of a Trail bike.
Overview of components
Fork
The SunTour XCM is included from the factory. It has a travel distance of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Fluid 3 HT 2018 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fluid 3 HT comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Fluid 3 HT comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
