Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Fork SunTour XCR
-
Groupset Deore, Acera -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New 2012 120 mm travel frame 26"
Suspension Fork
SR Suntour XCR LO 26 120 mm hydraulic lockout
Rear Shock
X Fusion E1 R
Drivetrain
Rear Derailleur
Shimano 9 speed Deore RD
Front Derailleur
Shimano Acera FD
Shift Levers
Jagwire LEX housing
Cassette
Shimano CS HG 20 9 speed
Crank
Shimano Acera Octalink 9 speed
Bottom Bracket
Shimano Octalink
Chain
SRAM PC 950 9 speed chain
Chain Tensioner
N/A
Pedals
Wellgo alloy body / steel cage MTB pedal
Wheels
Front Hub
Front loose ball hub
Rear Hub
Formula DC 25 rear 135 x 10 w/ QR axle
Rims
WTB SX 19 trail rim 26
Tires
Continental X-King 26 x 2.2
Brakes
Brakes
Avid Elixer 1 hydraulic disc brake
Brake Levers
N/A
Disk Rotors
N/A
Cockpit
Stem
Alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 740 mm width 25 mm rise bar
Grips
T-One MTB diamond grip Krayton
Headset
FSA # 10 headset internal 50 OD / 44 ID
Seat
Saddle
Norco MTB trail saddle
Seatpost
Norco 6061 alloy double bolt 2D forged head 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - | - | - |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.4 mm | 1.35 mm | 1.3 mm | 1.26 mm | 1.26 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm | 332 mm | 332 mm | 332 mm |
| Front Center | 640 mm | 666 mm | 692 mm | 718 mm | 744 mm | 744 mm |
| Rake | 40 mm | 40 mm | 39 mm | 40 mm | 40 mm | 40 mm |
| Trail | 92 mm | 92 mm | 93 mm | 92 mm | 92 mm | 92 mm |
| Stack | 551 mm | 561 mm | 570 mm | 579 mm | 588 mm | 588 mm |
| Reach | 378 mm | 400 mm | 423 mm | 445 mm | 467 mm | 467 mm |
| Top Tube Length | 537 mm | 562 mm | 587 mm | 612 mm | 637 mm | 637 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm | 470 mm | 510 mm | 510 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm | 150 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 1057 mm | 1083 mm | 1109 mm | 1135 mm | 1161 mm | 1161 mm |
| Bottom Bracket Drop | 5 mm | 5 mm | 5 mm | 5 mm | 5 mm | 5 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
Fluid 6.3 belongs to the Norco Fluid model. There are 60 bikes that carry this model name. Check out the entire range from 2013 of this model, by clicking this link.
Model range prices
Norco Fluid 6.3 2013 is the most affordable bike of this model and has a price of 1415$. On the other hand, Norco Fluid 9.1 2013, is the most expensive and costs 2457$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1415$. If we compare this with the average Trail bike cost we notice that the price is 95.19% smaller.
Fluid 6.3 components
Fork
The SunTour XCR is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Fluid 6.3 has a rear shock with a travel of 120mm. The model X Fusion E1 R is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Fluid 6.3 are the 26″ aluminum type. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fluid 6.3 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
