Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Reba
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid HT Plus 6061 Alloy Frame w/DB TT and DT
Suspension Fork
Rock Shox Reba RL 120mm/15mm
Rear Shock
Angular Sealed Cartridge Bearings - Tapered
Drivetrain
Rear Derailleur
Shimano SLX M7000 Shadow Plus 11spd
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Shimano M8000 11spd 11/46
Crank
Alloy Boost 32T Cranks
Bottom Bracket
External Threaded BB
Chain
KMX X11-1 11spd
Chain Tensioner
N/A
Pedals
VP Nylon Flat Pedal
Wheels
Front Hub
Novatec 110mm x 15mm
Rear Hub
Joytech Boost 141 RR QR 32H
Rims
Alex MD35 650B/26 Plus 32H
Tires
WTB Ranger 27.5"/26""x 2.8"""
Brakes
Brakes
Shimano SLX BRM7000 180mm
Brake Levers
Shimano SLX BRM7000
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy 60mm
Handlebar
N/A
Grips
N/A
Headset
Norco Grip
Seat
Saddle
Norco XC Saddle
Seatpost
TranzX 125mm Dropper Post 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.49 mm | 1.44 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 655 mm | 681 mm | 716 mm | 742 mm | 768 mm |
| Rake | 42 mm | 43 mm | 51 mm | 51 mm | 51 mm |
| Trail | 102 mm | 101 mm | 92 mm | 92 mm | 92 mm |
| Stack | 595 mm | 595 mm | 608 mm | 617 mm | 627 mm |
| Reach | 375 mm | 400 mm | 422 mm | 444 mm | 466 mm |
| Top Tube Length | 552 mm | 582 mm | 612 mm | 642 mm | 672 mm |
| Seat Tube Angle | 73.5 ° | 73.1 ° | 72.7 ° | 72.3 ° | 71.9 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 110 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 417 mm | 417 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1069 mm | 1095 mm | 1139 mm | 1165 mm | 1191 mm |
| Bottom Bracket Drop | 41 mm | 41 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 715 mm | 713 mm | 770 mm | 781 mm | 792 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Fluid 7.1/6.1 HT+ is part of the Norco Fluid Ht model. Norco released 78 bikes variations of this model so far. Take a sneak peek at all Norco Fluid Ht bikes models from 2017, by clicking here.
Model range prices
The most economical model, the Norco Fluid 7.3/6.3 HT+ 2017 has a starting price of 899$. Norco Fluid 7.1/6.1 HT+ 2017 on the other hand is the most expensive at 1699$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2017 for 1699$. Comparing the average cost of a Trail bike to this one, you will see that Fluid 7.1/6.1 HT+ price is 62.57% lower.
Fluid 7.1/6.1 HT+ components
Fork
Norco Fluid 7.1/6.1 HT+ 2017 bike is equipped with the RockShox Reba fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
As for the wheels, Norco Fluid 7.1/6.1 HT+ 2017, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fluid 7.1/6.1 HT+ has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Norco Fluid 7.1/6.1 HT+ includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
