Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset SLX, GX -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid forma alloy frame with 120 mm travel
Suspension Fork
Rockshox Recon SilverTK SA 120mm 15mm
Rear Shock
Rockshox Monarch RL HVI
Drivetrain
Rear Derailleur
Shimano SLX M-675 Shadow Plus 10 speed
Front Derailleur
SRAM GX high clamp mount FD downpull
Shift Levers
Jagwire LEX housing
Cassette
Shimano HG-50 11-36T 10 sp
Crank
SR Suntour 2 pc XCM 36/22 10 speed
Bottom Bracket
included with crank
Chain
KMC X-10
Chain Tensioner
N/A
Pedals
Wellgo resin body / alloy black cage MTB pedal
Wheels
Front Hub
Alloy disc w/15 mm / sealed bearing
Rear Hub
SRAM MTH 306 alloy disc w/ QR
Rims
Alex DP 21 dbl wall 650B I21 tubeless ready
Tires
N/A
Brakes
Brakes
Shimano M-396 hydraulic disc w/160mm rotor
Brake Levers
Shimano M-396
Disk Rotors
N/A
Cockpit
Stem
Alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 6061 alloy 25.4 mm rise bar 740mm
Grips
Norco MTB gator design trail grip
Headset
FSA #57B tapered internal
Seat
Saddle
WTB Deva XC trail womens design saddle
Seatpost
Alloy MTB stem with 4 bolt front clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.4 mm | 13.535 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm |
| Front Center | 655 mm | 678 mm | 700 |
| Rake | 42 mm | 41 mm | -1887 mm |
| Trail | 95 mm | 96 mm | 2168 mm |
| Stack | 567 mm | 574 mm | mm |
| Reach | 389 mm | 409 mm | 429 mm |
| Top Tube Length | 547 mm | 569 mm | 591 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 107 mm | 115 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1076 mm | 1098 mm | 1122 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm |
| Standover Height | 746 mm | 732 mm | 764 mm |
| Front Travel | 120 mm | 120 mm | 120 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
Fluid 7.2 Forma belongs to the Norco Fluid model. 60 bikes variations carry this model name so far. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
The most economical model, the Norco Fluid 2.2 2016 has a starting price of 1495$. Norco Fluid 7.1 2016 on the other hand is the most expensive at 2325$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2016, its price was 1775$. Comparing this to the average Trail bike price, we see that the price is 55.61% smaller.
Fluid 7.2 Forma components
Fork
This bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is Rockshox Monarch RL HVI, with a travel distance of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the Fluid 7.2 Forma bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid 7.2 Forma is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 3 sizes. They vary from 151 cm – 179 cm (4.95 ft – 5.87 ft). In short, it won’t be difficult to find the right one for you.
