Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 120mm -
Travel Rear 100mm -
Fork Manitou JUNIT
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
20"
115cm - 129cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum, 100mm Travel, tapered headtube, boost axle spacing, ISCG05 mount
Suspension Fork
Manitou J-Unit 20", TS Air, Alloy Steerer 120mm Travel
Rear Shock
X-Fusion 02 Pro R, custom light tune
Drivetrain
Rear Derailleur
SRAM GX Short Cage
Shift Levers
SRAM GX Trigger 10 speed
Cassette
Sunrace MS1 11-36T
Crank
Samox AM38J 3 piece 140mm, narrow/wide 30T
Bottom Bracket
square taper
Chain
KMC X10
Pedals
Jr flat resin, metal pins
Wheels
Front Hub
Alloy 6 Bolt Disc, Boost 15x110
Rear Hub
Alloy 12x148mm Boost
Rims
Alloy Double Wall Disc
Tires
Front: Vee Rubber Crown Gem 20x2.25", Skinwall, Rear: Vee Rubber Crown Gem 20x2.25", Skinwall
Brakes
Brakes
Front: Tektro HD-M276 Hydraulic, Jr lever, 160mm, Rear: Tektro HD-M276 Hydraulic, Jr lever, 160mm
Cockpit
Stem
35mm reach MTB
Handlebar
Alloy, 620mm, 15mm Rise
Grips
Norco Jr 92mm, lock on
Headset
FSA #57 E
Seat
Saddle
Norco Jr. MTB Saddle
Seatpost
Norco alloy post with micro adjust head
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 20" |
|---|---|
| Stack Reach Ratio | 1.4 mm |
| Bottom Bracket Height | 270 mm |
| Front Center | 285 mm |
| Rake | 40 mm |
| Trail | 83 mm |
| Stack | 434 mm |
| Reach | 311 mm |
| Top Tube Length | 430 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 255 mm |
| Head Tube Angle | 64 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 346 mm |
| Wheelbase | 631 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 491 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 129 cm |
Model Overview
Fluid FS 2.2 is part of the Norco Fluid Fs model. Norco released 111 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Norco Fluid 2 FS 20 2022 is the cheapest bike model and costs 1999$. Norco Fluid FS 4.1 2022 is the most expensive one and costs 2799$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Mountain bikes
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, you could also get a good Mountain bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 1999$. Doing a quick comparison, we notice that Fluid FS 2.2 price is 224.51% more expensive than the average cost of a Mountain bike.
Fluid FS 2.2 components
Fork
The Manitou JUNIT is included from the factory. It has a travel distance of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
From the factory, it comes with the X-Fusion 02 Pro R rear shock model, which has a travel of 100mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When it comes to wheels, the Fluid FS 2.2 bike is equipped with the 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike has one size only, so it might not fit you. In conclusion, double-check its size to make sure it’s a good fit for you.
