Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Sektor
-
Groupset NX, NX Eagle -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Fluid FS, Aluminum, 120mm Travel, Boost 12x148mm TA Dropouts
Suspension Fork
RockShox Sektor RL, 130mm Travel, Boost 15x110mm TA
Rear Shock
RockShox Deluxe R, 190x45mm (29") | 190x42.5mm (27.5"), DebonAir
Drivetrain
Rear Derailleur
SRAM NX, 11 Speed
Front Derailleur
-
Shift Levers
Rear: SRAM NX, 11 Speed, Front: -
Cassette
SRAM NX PG-1130, 11-42T, 11 Speed
Crank
SRAM NX Eagle, 170mm (XS/S) | 175mm (M/L/XL), 30T
Bottom Bracket
SRAM DUB BB, Threaded BSA 73mm
Chain
SRAM NX PC-1110, 11 Speed
Chain Guide
None
Pedals
VP Nylon Flat Pedals, 9/16"
Wheels
Front Hub
Novatec Boost 110mm x 15mm 32H
Rear Hub
Novatec D162SB, Boost 12x148mm
Rims
WTB STP i29 TCS, 32 Hole, 29mm Internal Width
Spokes
Stainless steel 14g, black
Tires
Maxxis Forekaster, 2.6”, 3C/EXO/TR, Folding
Brakes
Brakes
SRAM Level T, 2 Piston Hydraulic Disc, Avid G2 180mm Rotor
Brake Levers
SRAM Level T
Cockpit
Stem
TranzX 6061 Alloy 50mm/35mm
Handlebar
TranzX 6061 DB Alloy 780mm
Grips
VP, Lock-On
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco XC Saddle
Seatpost
TranzX YSP18JL Stealth Dropper, 100mm (XS) | 120mm (S) | 130mm (M/L/XL) Travel, 31.6mm, 1x Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 671 mm | 705 mm | 739 mm |
| Rake | 42 mm | 42 mm | 41 mm |
| Trail | 112 mm | 112 mm | 113 mm |
| Stack | 572 mm | 581 mm | 591 mm |
| Reach | 384 mm | 414 mm | 444 mm |
| Top Tube Length | 526 mm | 558 mm | 590 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 370 mm | 390 mm | 420 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1105 mm | 1139 mm | 1173 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm |
| Standover Height | 754 mm | 754 mm | 764 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
Fluid FS 2 27.5 completes the Norco Fluid Fs model. Norco launched 111 bikes of this model so far. Take a sneak peek at all Norco Fluid Fs bikes models from 2019, by clicking here.
Model range prices
Norco Fluid FS 4 Women’s 29 2019 is the most economical model, with a starting price of 1649$. Norco Fluid FS 1 29 2019 on the other hand costs 3049$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2019 for 2699$. If we compare this with the average Trail bike cost we notice that the price is 2.33% lower.
Overview of components
Fork
Norco Fluid FS 2 27.5 2019 bike is equipped with the RockShox Sektor fork, and has 130mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the RockShox Deluxe R rear shock model, which has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on Fluid FS 2 27.5 are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 151 cm – 179 cm (4.95 ft – 5.87 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Norco Fluid FS 2 27.5 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
