Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, Suntour SR -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid aluminum w/120 mm travel
Suspension Fork
Rockshox Recon RL Silver Solo 120mm 15x110mm boost
Rear Shock
Rockshox Monarch R HVI High Volume Eyelet
Drivetrain
Rear Derailleur
Shimano Deore M6000 Shadow Plus SGS 10 speed
Shift Levers
Shimano Deore SLM-6000 10spd
Cassette
Sunrace CSMS2 Black 10sp 11-42T Cassette
Crank
SR Suntour Zeron Boost 30T Cranks w/1X narrow/wide ring
Bottom Bracket
SR Suntour cartridge BB
Chain
KMC X 10
Pedals
Wellgo resin body / alloy black cage MTB pedal
Wheels
Front Hub
Alloy disc w/15 mm with sealed bearing
Rear Hub
Joy tech disc hub w/QR 10/11sp cassette
Rims
WTB I25 32H, 25mm inner, TRS tubeless
Tires
WTB Vigalante 27.5x2.3
Brakes
Brakes
Tektro Hydraulic Disc brake HD-M285 w/180mm
Brake Levers
Tektro HD-M285
Cockpit
Stem
Alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 25mm rise 6061 DB alloy 760mm
Grips
Norco Gator grip
Headset
FSA #57B tapered internal
Seat
Saddle
WTB Volt Sport trail saddle
Seatpost
Norco 6061 alloy double bolt 30.9 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.4 mm | 13.535 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm |
| Front Center | 655 mm | 678 mm | 700 |
| Rake | 42 mm | 41 mm | -1887 mm |
| Trail | 95 mm | 96 mm | 2168 mm |
| Stack | 567 mm | 574 mm | mm |
| Reach | 389 mm | 409 mm | 429 mm |
| Top Tube Length | 547 mm | 569 mm | 591 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 107 mm | 115 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1076 mm | 1098 mm | 1122 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm |
| Standover Height | 746 mm | 732 mm | 764 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
Model Overview
Fluid FS 3 27.5 is a Norco Fluid Fs model. 111 bikes variations carry this model name so far. Take a sneak peek at all Norco Fluid Fs bikes models from 2018, by clicking here.
Model range prices
Norco Fluid FS 2.2 2018 is the most economical model, with a starting price of 1599$. Norco Fluid FS1+ Womens 2018 on the other hand costs 2199$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Norco released this model in 2018, its price was 1749$. Comparing the average cost of a Trail bike to this one, you will see that Fluid FS 3 27.5 price is 57.92% smaller.
Overview of components
Fork
Norco Fluid FS 3 27.5 2018 bike is equipped with the RockShox Recon Silver RL fork, and has 120mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Fluid FS 3 27.5 has a rear shock with a travel of 120mm. The model Rockshox Monarch R HVI High Volume Eyelet is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on Fluid FS 3 27.5 are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fluid FS 3 27.5 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, you won’t have a problem finding one that suits you.
