Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset NX, Truvativ Stylo -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Fluid FS, Aluminum, 120mm Travel, Boost 12x148mm TA Dropouts
Suspension Fork
RockShox Recon RL, 130mm Travel, Boost 15x110mm TA
Rear Shock
RockShox Deluxe R, 190x45mm (29") | 190x42.5mm (27.5"), DebonAir
Drivetrain
Rear Derailleur
SRAM NX, 11 Speed
Front Derailleur
-
Shift Levers
Rear: SRAM NX, 11 Speed, Front: -
Cassette
SRAM NX PG-1130, 11-42T, 11 Speed
Crank
Truvativ Stylo 6K, 170mm (XS/S) | 175mm (M/L/XL), 30T
Bottom Bracket
Truvativ PowerSpline BB, Threaded BSA 73mm
Chain
SRAM NX PC-1110, 11 Speed
Chain Guide
None
Pedals
VP Nylon Flat Pedals, 9/16"
Wheels
Front Hub
Alloy Boost 110mm x 15mm
Rear Hub
Joytech D342TSE, Boost 12x148mm
Rims
WTB STP i29 TCS, 32 Hole, 29mm Internal Width
Spokes
Stainless steel 14g, black
Tires
Maxxis Forekaster, 2.6”, EXO/TR, Folding
Brakes
Brakes
Tektro Auriga HD-M290, 2 Piston Hydraulic Disc, 180mm Rotor
Brake Levers
Tektro HD-M275
Cockpit
Stem
TranzX 6061 Alloy 50mm/35mm
Handlebar
TranzX 6061 DB Alloy 780mm
Grips
VP, Lock-On
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco XC Saddle
Seatpost
TranzX YSP18JL Stealth Dropper, 100mm (XS) | 120mm (S) | 130mm (M/L/XL) Travel, 31.6mm, 1x Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.3 mm | 1.24 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 743 mm | 777 mm | 811 mm |
| Rake | 50 mm | 51 mm | 51 mm |
| Trail | 108 mm | 107 mm | 107 mm |
| Stack | 606 mm | 615 mm | 624 mm |
| Reach | 443 mm | 473 mm | 503 mm |
| Top Tube Length | 593 mm | 626 mm | 658 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1172 mm | 1207 mm | 1240 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm |
| Standover Height | 763 mm | 773 mm | 783 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Fluid FS 3 29 is part of the Norco Fluid Fs model. There are 111 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Norco Fluid FS 4 Women’s 29 2019 is the most affordable bike of this model and has a price of 1649$. On the other hand, Norco Fluid FS 1 29 2019, is the most expensive and costs 3049$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2199$. Comparing the average cost of a Trail bike to this one, you will see that Fluid FS 3 29 price is 25.6% lower.
Fluid FS 3 29 components
Fork
The Fluid FS 3 29 comes factory-installed with the RockShox Recon Silver RL fork. This has a travel range of 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the RockShox Deluxe R rear shock model, which has a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
As for the wheels, Norco Fluid FS 3 29 2019, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid FS 3 29 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
