Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 145mm -
Travel Rear 120mm -
Fork Manitou JUNIT
-
Groupset Deore, SX Eagle -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
24"
128cm - 142cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum,120mm Travel, tapered headtube, boost axle spacing, ISCG05 mount
Suspension Fork
Manitou J-Unit 24" TS Air, Alloy Steerer, 145mm Travel
Rear Shock
X-Fusion 02 Pro R, custom light tune
Drivetrain
Rear Derailleur
Shimano Deore M6000
Shift Levers
Shimano Deore SL-M6000 10 speed
Cassette
Shimano Deore HG500 11/42T
Crank
SRAM SX Eagle, 155mm, 30T
Bottom Bracket
SRAM PowerSpline
Chain
KMC X10
Pedals
Jr flat resin, metal pins
Wheels
Front Hub
15x110 Boost
Rear Hub
Alloy, 12x148mm Boost
Rims
Alloy Double Wall Disc
Tires
Front: Vee Rubber Crown Gem 24x2.25", Rear: Vee Rubber Crown Gem 24x2.25"
Brakes
Brakes
Front: Tektro HD-M276 Hydraulic, 180mm, Rear: Tektro HD-M276 Hydraulic, 180mm
Cockpit
Stem
35mm reach MTB
Handlebar
Alloy 660mm, 15mm Rise
Grips
Jr. Soft Krayton Rubber lock on
Headset
FSA #57 E
Seat
Saddle
Norco Jr. MTB
Seatpost
JD TransX Light Action Dropper, 100mm,1x lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.51 mm |
| Bottom Bracket Height | 305 mm |
| Front Center | 645 mm |
| Rake | 40 mm |
| Trail | 106 mm |
| Stack | 538 mm |
| Reach | 357 mm |
| Top Tube Length | 499 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 305 mm |
| Head Tube Angle | 64.5 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 414 mm |
| Wheelbase | 1059 mm |
| Bottom Bracket Drop | 5 mm |
| Standover Height | 576 mm |
| Wheels | 24" |
| Rider Min Height | 128 cm |
| Rider Max Height | 142 cm |
About this model
Fluid FS 4.2 is part of the Norco Fluid Fs model. There are 111 bikes that carry this model name. Take a sneak peek at all Norco Fluid Fs bikes models from 2022, by clicking here.
Model range prices
Norco Fluid 2 FS 20 2022 is the most economical model, with a starting price of 1999$. Norco Fluid FS 4.1 2022 on the other hand costs 2799$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Mountain bikes
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2099$. Doing a quick comparison, we notice that Fluid FS 4.2 price is 240.75% more expensive than the average cost of a Mountain bike.
Overview of components
Fork
The fork installed on this bike is the Manitou JUNIT model. The travel on this model is 145mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
Fluid FS 4.2 has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
The shock that’s installed on this bike is X-Fusion 02 Pro R, with a travel distance of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Norco Fluid FS 4.2 2022, has a 24″ aluminum model. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid FS 4.2 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike has one size only, so it might not fit you. In conclusion, make sure it fits you, or look for another model.
Dropper post
A dropper post is included with the Fluid FS 4.2. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
