Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork SunTour XCR 34
-
Groupset Deore, Suntour SR -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Fluid FS, Aluminum, 120mm Travel, Boost 12x148mm TA Dropouts
Suspension Fork
SR Suntour XCR34 AIR, 130mm Travel, Boost 15x110mm TA, LOR/DS
Rear Shock
X-Fusion O2 Pro R, 190x45mm (29") | 190x42.5mm (27.5")
Drivetrain
Rear Derailleur
Shimano Deore M6000, SGS/Shadow Plus, 10 Speed
Front Derailleur
-
Shift Levers
Rear: Shimano Deore SL-M6000, 10 Speed, Front: -
Cassette
Shimano Deore CS-HG500, 11-42T, 10 Speed
Crank
SR Suntour Zeron Boost, 170mm (XS/S) | 175mm (M/L/XL), 30T
Bottom Bracket
SR Suntour BB24, Threaded BSA 73mm
Chain
KMC X10, 10 Speed
Chain Guide
None
Pedals
VP Nylon Flat Pedals, 9/16"
Wheels
Front Hub
Novatec Boost 110mm x 15mm
Rear Hub
Joytech D342TSE, Boost 12x148mm
Rims
WTB STP i29 TCS, 32 Hole, 29mm Internal Width
Spokes
Stainless steel 14g, black
Tires
Goodyear Escape, 2.6”
Brakes
Brakes
Tektro HD-M275, 2 Piston Hydraulic Disc, 180mm Rotor
Brake Levers
Tektro HD-M275
Cockpit
Stem
TranzX 6061 Alloy 50mm/35mm
Handlebar
TranzX 6061 DB Alloy 780mm
Grips
VP, Lock-On
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco XC Saddle
Seatpost
TranzX YSP18JL Stealth Dropper, 100mm (XS) | 120mm (S/M/L/XL) Travel, 31.6mm, 1x Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.3 mm | 1.24 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 743 mm | 777 mm | 811 mm |
| Rake | 50 mm | 51 mm | 51 mm |
| Trail | 108 mm | 107 mm | 107 mm |
| Stack | 606 mm | 615 mm | 624 mm |
| Reach | 443 mm | 473 mm | 503 mm |
| Top Tube Length | 593 mm | 626 mm | 658 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1172 mm | 1207 mm | 1240 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm |
| Standover Height | 763 mm | 773 mm | 783 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Fluid FS 4 29 completes the Norco Fluid Fs model. There are 111 bikes that carry this model name. Take a sneak peek at all Norco Fluid Fs bikes models from 2019, by clicking here.
Model range prices
Norco Fluid FS 4 Women’s 29 2019 is the most economical model, with a starting price of 1649$. Norco Fluid FS 1 29 2019 on the other hand costs 3049$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2019 and its price was 1799$. Comparing this to the average Trail bike price, we see that the price is 53.53% lower.
Fluid FS 4 29 components
Fork
This bike has the SunTour XCR 34 fork installed. The fork’s travel is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is X-Fusion O2 Pro R, with a travel distance of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When it comes to wheels, the Fluid FS 4 29 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fluid FS 4 29 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Fluid FS 4 29. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
