Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid 29er alloy frame with 120 mm travel
Suspension Fork
Rockshox Recon Silver RL solo air 120x15mm
Rear Shock
Rockshox Monarch R HVI
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus SGS 10 speed
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Sunrace 11/40 T cassette
Crank
SAMOX w / steel 1 x ring
Bottom Bracket
73mm cartridge type
Chain
KMC X 10
Chain Tensioner
N/A
Pedals
Wellgo resin body / alloy black cage MTB pedal
Wheels
Front Hub
Novatec alloy disc 100x15mm, sealed bearing
Rear Hub
Novatec alloy Q/R 10/11sp cass hub semi sealed
Rims
WTB STP I 23 TCS tubeless compatible rim
Tires
Maxxis Ardent 29x2.25
Brakes
Brakes
Tektro Hydraulic Disc brake HD-M285 w/160mm
Brake Levers
Tektro
Disk Rotors
N/A
Cockpit
Stem
Alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 25mm rise 6061 DB alloy 740/760mm
Grips
Norco MTB gator design trail grip
Headset
FSA #57B tapered internal
Seat
Saddle
WTB Volt Sport trail saddle
Seatpost
JD TransX dropper post w/remote lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.659 mm | 1.543 mm | 1.466 mm | 1.397 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 639 mm | 663 mm | 694 mm | 725 mm |
| Rake | 51 mm | 47 mm | 46 mm | 46 mm |
| Trail | 86 mm | 90 mm | 91 mm | 91 mm |
| Stack | 612 mm | 614 mm | 623 mm | 633 mm |
| Reach | 369 mm | 398 mm | 425 mm | 453 mm |
| Top Tube Length | 550 mm | 580 mm | 610 mm | 640 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm | 535 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1086 mm | 1111 mm | 1141 mm | 1172 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 780 mm | 795 mm | 793 mm | 779 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Fluid FS 9.2 belongs to the Norco Fluid Fs model. Norco launched 111 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Norco Fluid FS 6.2 2017 is the most economical model, with a starting price of 1699$. Norco Fluid FS 7.1+ 2017 on the other hand costs 2149$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Norco Fluid FS 9.2 price was 1699$. If we compare this with the average Trail bike cost we notice that the price is 62.57% smaller.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Fluid FS 9.2 has a rear shock with a travel of 120mm. The model Rockshox Monarch R HVI is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the Fluid FS 9.2 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Fluid FS 9.2 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Norco Fluid FS 9.2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Norco Fluid FS 9.2 comes with a dropper post. Therefore, climbing or descending will be a breeze.
