Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Marzocchi Bomber Z2
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 193cm
XXL
190cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, 130mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
Suspension Fork
Marzocchi Bomber Z2, 140mm Travel, 44mm Offset
Rear Shock
Fox FLOAT X Performance, Custom Tune, 210x50mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano SLX SL-M7100-IR I-Spec EV
Cassette
Shimano SLX, 10-51, 12 Speed
Crank
Praxis G2 Cadet M24, 30T, 170mm (S), 175mm (M - XXL)
Bottom Bracket
Praxis M24 Cartridge Bearing, BSA Threaded
Chain
Shimano Deore
Pedals
VP Nylon Flat
Wheels
Front Hub
Bear Pawls Sealed Bearing, 15x110mm Boost, 6 Bolt
Rear Hub
Bear Pawls Sealed Bearing, 12x148mm Boost, Micro Spline, 6 Bolt
Rims
Stan's Flow D, 29", 32H
Tires
Front: Vittoria Mazza 2.4" Trail G2.0, Folding, Rear: Vittoria Mazza 2.4" Trail G2.0, Folding
Brakes
Brakes
Front: TRP Slate EVO, 4 Piston, Organic Pads, Rear: TRP Slate EVO, 4 Piston, Organic Pads
Brake Levers
TRP Slate EVO
Cockpit
Stem
6061 Alloy, 40mm Length, 35mm Clamp
Handlebar
e*thirteen 800mm, 20mm Rise
Grips
WTB Waffle, Lock-On
Headset
Sealed Bearing, Tapered
Seat
Saddle
Fizik Alpaca Terra with Wingflex
Seatpost
SDG Tellis Dropper, 34.9mm, 150mm (s), 170mm (M, L), 200mm (XL, XXL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.4 mm | 1.33 mm | 1.27 mm | 1.21 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 743 mm | 777 mm | 812 mm | 846 mm | 880 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 128 mm | 128 mm | 128 mm | 128 mm | 128 mm |
| Stack | 611 mm | 620 mm | 629 mm | 638 mm | 647 mm |
| Reach | 414 mm | 444 mm | 474 mm | 504 mm | 534 mm |
| Top Tube Length | 568 mm | 596 mm | 624 mm | 653 mm | 681 mm |
| Seat Tube Angle | 76 ° | 76.3 ° | 76.7 ° | 77 ° | 77.3 ° |
| Seat Tube Length | 360 mm | 390 mm | 410 mm | 460 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 419 mm | 424 mm | 429 mm | 434 mm | 439 mm |
| Wheelbase | 1160 mm | 1199 mm | 1239 mm | 1278 mm | 1317 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 672 mm | 684 mm | 693 mm | 730 mm | 761 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm | 190 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 193 cm | 200 cm |
About this model
Fluid FS A2 belongs to the Norco Fluid Fs model. 111 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Norco Fluid FS Youth 27.5 2023 has a starting price of 1655$. Norco Fluid FS A1 2023 on the other hand is the most expensive at 3999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2023 and its price was 3149$. In conclusion, this bike price is 14.01% more expensive than the price of the average Trail bike.
Overview of components
Fork
The Fluid FS A2 comes factory-installed with the Marzocchi Bomber Z2 fork. This has a travel range of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Fluid FS A2 has a rear shock with a travel of 130mm. The model Fox FLOAT X Performance is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the Fluid FS A2 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fluid FS A2 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Norco Fluid FS A2 bike has 5 sizes, in the range of 154 cm – 200 cm (5.05 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the Fluid FS A2. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
