Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Pike Select
-
Groupset NX Eagle, SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fibre Main Triangle, Aluminum Stays, 130mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
Suspension Fork
RockShox Pike Select, 140mm Travel, 44mm Offset
Rear Shock
RockShox Super Deluxe Select+, 210x50mm, Custom Tune
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle MMX
Cassette
SRAM PG1210 Eagle, 11-50T
Crank
SRAM SX Eagle DUB, 30T, 170mm (S), 175mm (M-XL)
Bottom Bracket
SRAM DUB, BSA Threaded
Chain
SRAM SX Eagle
Wheels
Front Hub
Bear Pawls, 15x110mm Boost, 6 Bolt
Rear Hub
Bear Pawls, 15x148mm Boost, HG, 6 Bolt
Rims
WTB ST, 29", 32H
Tires
Front: Vittoria Mazza 2.4" Trail G2.0, Folding, Rear: Vittoria Mazza 2.4" Trail G2.0, Folding
Brakes
Brakes
Front: SRAM DB8, Sintered Pads, Rear: SRAM DB8, Sintered Pads
Brake Levers
SRAM DB8
Cockpit
Stem
6061 Alloy, 40mm Length, 35mm Clamp
Handlebar
6061 Butted Alloy, 800mm, 25mm Rise
Grips
WTB Wavelength
Headset
FSA Sealed Bearing, Tapered
Seat
Saddle
Fizik Alpaca Terra with Wingflex
Seatpost
Tranz-X Dropper, 34.9mm, 150mm (S), 170mm (M), 200mm (L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.4 mm | 1.33 mm | 1.27 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 743 mm | 777 mm | 812 mm | 846 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 128 mm | 128 mm | 128 mm | 128 mm |
| Stack | 611 mm | 620 mm | 629 mm | 638 mm |
| Reach | 414 mm | 444 mm | 474 mm | 504 mm |
| Top Tube Length | 568 mm | 596 mm | 624 mm | 653 mm |
| Seat Tube Angle | 76 ° | 76.3 ° | 76.7 ° | 77 ° |
| Seat Tube Length | 360 mm | 390 mm | 410 mm | 460 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 419 mm | 424 mm | 429 mm | 434 mm |
| Wheelbase | 1160 mm | 1199 mm | 1239 mm | 1278 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 672 mm | 684 mm | 693 mm | 730 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
Model Overview
Fluid FS C3 belongs to the Norco Fluid Fs model. Norco released 111 bikes variations of this model so far. You can easily view all of the Norco Fluid Fs bikes models from 2024, here.
Model range prices
Norco Fluid FS C3 2024 is the most economical model, with a starting price of 4099$. Norco Fluid FS C1 2024 on the other hand costs 5999$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2024 for 4099$. In conclusion, this bike price is 48.41% higher than the price of the average Trail bike.
Fluid FS C3 components
Fork
The fork installed on this bike is the RockShox Pike Select model. The travel on this model is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe Select+ model, with a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Fluid FS C3 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fluid FS C3 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Fluid FS C3 comes in 4 sizes, that range from 154 cm – 191 cm (5.05 ft – 6.27 ft). In short, you can easily find one that suits you.
Dropper post
Norco Fluid FS C3 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
