Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid aluminum 650B Plus 120mm travel
Suspension Fork
Rockshox Recon RL Silver 130mm, Solo Air, Boost 15x110mm
Rear Shock
Rockshox Monarch RL HVI
Drivetrain
Rear Derailleur
Shimano SLX M7000 Shadow Plus 11spd
Shift Levers
Shimano SLX M7000 11spd I-Spec
Cassette
Sunrace CSMS8 11sp 11/46 Cassette
Crank
Samox Boost crank w/30T aluminum 1X narrow/wide ring
Bottom Bracket
Samox external cartridge BB
Chain
KMX X11-1 11spd
Pedals
VP aluminum MTB/BMX flat pedal
Wheels
Front Hub
Joytech aluminum w/disc mount, boost 110x15mm
Rear Hub
Joytech disc hub w/Boost 141 w/QR
Rims
Alex MD 35 650B+ 32H, 35mm TRS tubelesss compatible
Tires
Maxxis Forecaster 27.5x2.8 folding, dual compound EXO/TR
Brakes
Brakes
Shimano Alivio M-365 hydraulic disc w/180mm rotor
Brake Levers
Shimano Alivio
Cockpit
Stem
Alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 25mm rise 6061 DB alloy 740/760mm
Grips
Norco Grip
Headset
FSA #57B tapered internal
Seat
Saddle
WTB Volt
Seatpost
JD TransX YSP12 stealth dropper post w/remote lever, 80mm SM, 100mm Med, 125mm L/XL, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.534 mm | 1.426 mm | 1.358 mm | 1.302 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 684 mm | 714 mm | 744 mm | 775 mm |
| Rake | 52 mm | 52 mm | 51 mm | 51 mm |
| Trail | 88 mm | 88 mm | 89 mm | 89 mm |
| Stack | 606 mm | 606 mm | 615 mm | 625 mm |
| Reach | 395 mm | 425 mm | 453 mm | 480 mm |
| Top Tube Length | 575 mm | 605 mm | 635 mm | 665 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm | 535 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1132 mm | 1162 mm | 1193 mm | 1224 mm |
| Bottom Bracket Drop | 31 mm | 31 mm | 31 mm | 31 mm |
| Standover Height | 767 mm | 756 mm | 785 mm | 785 mm |
| Front Travel | 130 mm | 130 mm | 130 mm | 130 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Fluid FS1+ completes the Norco Fluid Fs model. Norco launched 111 bikes of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Norco Fluid FS 2.2 2018 is the most affordable bike of this model and has a price of 1599$. On the other hand, Norco Fluid FS1+ Womens 2018, is the most expensive and costs 2199$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Norco Fluid FS1+ price was 2199$. In conclusion, this bike price is 25.6% smaller than the price of the average Trail bike.
Overview of components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The Fluid FS1+ has a rear shock with a travel of 120mm. The model Rockshox Monarch RL HVI is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When leaving the production line, the Fluid FS1+ model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fluid FS1+ comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Fluid FS1+ comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Fluid FS1+. Therefore, climbing or descending will be a breeze.
