Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" / 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, Suntour SR -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid aluminum w/120 mm travel
Suspension Fork
Rockshox Recon RL Silver Solo 120mm 15x110mm boost
Rear Shock
Rockshox Monarch R HVI High Volume Eyelet
Drivetrain
Rear Derailleur
Shimano Deore M6000 Shadow Plus SGS 10 speed
Shift Levers
Shimano Deore SLM-6000 10spd
Cassette
Sunrace CSMS2 Black 10sp 11-42T Cassette
Crank
SR Suntour Zeron Boost 30T Cranks w/1X narrow/wide ring
Bottom Bracket
SR Suntour cartridge BB
Chain
KMC X 10
Pedals
Wellgo resin body / alloy black cage MTB pedal
Wheels
Front Hub
Alloy disc w/15 mm with sealed bearing
Rear Hub
Joy tech disc hub w/QR 10/11sp cassette
Rims
WTB I25 32H, 25mm inner, TRS tubeless
Tires
WTB Vigalante 27.5x2.3
Brakes
Brakes
Tektro Hydraulic Disc brake HD-M285 w/180mm
Brake Levers
Tektro HD-M285
Cockpit
Stem
Alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 25mm rise 6061 DB alloy 760mm
Grips
Norco Gator grip
Headset
FSA #57B tapered internal
Seat
Saddle
WTB Volt Sport trail saddle
Seatpost
Norco 6061 alloy double bolt 30.9 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.66 mm | 1.4 mm | 1.55 mm | 13.535 mm | 1.47 mm | 1.4 mm |
| Bottom Bracket Height | 332 mm | 334 mm | 332 mm | 334 mm | 332 mm | 334 mm | 334 mm |
| Front Center | 655 mm | 639 mm | 678 mm | 663 mm | 700 | 694 mm | 725 mm |
| Rake | 42 mm | 51 mm | 41 mm | 47 mm | -1887 mm | 46 mm | 46 mm |
| Trail | 95 mm | 86 mm | 96 mm | 90 mm | 2168 mm | 91 mm | 91 mm |
| Stack | 567 mm | 609 mm | 574 mm | 611 mm | mm | 620 mm | 630 mm |
| Reach | 389 mm | 366 mm | 409 mm | 395 mm | 429 mm | 422 mm | 450 mm |
| Top Tube Length | 547 mm | 547 mm | 569 mm | 577 mm | 591 mm | 607 mm | 637 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 74.5 ° | 73.5 ° | 74.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 400 mm | 405 mm | 445 mm | 435 mm | 490 mm | 535 mm |
| Head Tube Angle | 68.5 ° | 69.5 ° | 68.5 ° | 69.5 ° | 68.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 100 mm | 107 mm | 100 mm | 115 mm | 110 mm | 120 mm |
| Chainstay Length | 422 mm | 447 mm | 422 mm | 447 mm | 422 mm | 447 mm | 447 mm |
| Wheelbase | 1076 mm | 1083 mm | 1098 mm | 1108 mm | 1122 mm | 1138 mm | 1169 mm |
| Bottom Bracket Drop | 18 mm | 39 mm | 18 mm | 39 mm | 18 mm | 39 mm | 39 mm |
| Standover Height | 746 mm | 777 mm | 732 mm | 792 mm | 764 mm | 790 mm | 776 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 29" | 27" | 29" | 27" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 195 cm |
About this model
Fluid FS3 belongs to the Norco Fluid Fs model. Norco launched 111 bikes of this model so far. You can easily view all of the Norco Fluid Fs bikes models from 2018, here.
Model range prices
Norco Fluid FS 2.2 2018 is the most economical model, with a starting price of 1599$. Norco Fluid FS1+ Womens 2018 on the other hand costs 2199$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2018 and its price was 1749$. In conclusion, this bike price is 57.92% smaller than the price of the average Trail bike.
Fluid FS3 components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Norco Fluid FS3 bike has the Rockshox Monarch R HVI High Volume Eyelet model installed, and has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Fluid FS3 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
