Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid 6061 Alloy XC Frame w/DB TT & DT
Suspension Fork
Rock Shox Recon RL 120mm
Drivetrain
Rear Derailleur
SRAM NX 11spd
Shift Levers
SRAM NX 11spd
Cassette
SRAM PG-1130 11/42 Cassette
Crank
Samox Alloy DM 30T Alloy C/R
Bottom Bracket
Samox EB2401 External BB
Chain
SRAM PC-1110 11spd
Pedals
VP Nylon Flat Pedal
Wheels
Front Hub
Novatec Boost 110mm x 15mm
Rear Hub
Joytech Boost RR QR 32H
Rims
Alex MD35 650B Plus 32H
Tires
WTB Ranger 27.5"x 2.8"
Brakes
Brakes
Tektro HD-M285 Hydraulic 160mm
Brake Levers
Tektro HD-M285
Cockpit
Stem
Alloy 60mm x 31.8
Handlebar
X6 Alloy 750mm x 31.8
Grips
Norco Grip
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco XC Saddle
Seatpost
TranzX 125mm Dropper Post 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.34 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Front Center | 716 mm | 742 mm | 768 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 92 mm | 92 mm | 92 mm |
| Stack | 617 mm | 626 mm | 636 mm |
| Reach | 431 mm | 453 mm | 475 mm |
| Top Tube Length | 621 mm | 651 mm | 681 mm |
| Seat Tube Angle | 72.7 ° | 72.3 ° | 71.9 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1148 mm | 1174 mm | 1200 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Standover Height | 779 mm | 790 mm | 801 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Fluid HT 2 27.5 is part of the Norco Fluid Ht model. 78 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Norco Fluid HT 3 Womens 27.5 2018 is the most affordable bike of this model and has a price of 899$. On the other hand, Norco Fluid 1 HT Womens 2018, is the most expensive and costs 1749$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1349$. Comparing the average cost of a Trail bike to this one, you will see that Fluid HT 2 27.5 price is 104.74% lower.
Overview of components
Fork
The Fluid HT 2 27.5 comes factory-installed with the RockShox Recon Silver RL fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the Fluid HT 2 27.5 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Fluid HT 2 27.5 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Norco Fluid HT 2 27.5 bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Norco Fluid HT 2 27.5 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
