Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork SunTour XCR 34
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Frame, butted TT & DT
Suspension Fork
SR-Suntour XCR34, Air, 120mm Travel
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle 12 speed
Cassette
SRAM PG-1210 Eagle, 11-50T
Crank
SRAM SX Eagle, 30T
Bottom Bracket
Truvativ PowerSpline
Chain
SRAM SX Eagle
Pedals
VP Flat nylon
Wheels
Front Hub
Alloy 15x110mm Boost
Rear Hub
Alloy 12x148mm Boost, 32H
Rims
Alex DP30 TRS 29"/27.5"
Tires
Schwalbe Smart Sam 2.6"
Brakes
Brakes
Tektro HD-M275 Hydraulic, 180mm
Cockpit
Stem
Norco Alloy, 50mm, 31.8mm bore
Handlebar
X6 Alloy, 750mm, 31.8 bore
Grips
VP lock on
Headset
Sealed Cartridge Bearing
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18, 31.6mm, 130mm stealth dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.33 mm | 1.27 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm |
| Front Center | 742 mm | 776 mm | 810 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 109 mm | 109 mm | 109 mm |
| Stack | 622 mm | 631 mm | 640 mm |
| Reach | 443 mm | 473 mm | 503 mm |
| Top Tube Length | 615 mm | 647 mm | 680 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1169 mm | 1203 mm | 1237 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Standover Height | 664 mm | 680 mm | 704 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Fluid HT 2 29 completes the Norco Fluid Ht model. 78 bikes variations carry this model name so far. You can easily view all of the Norco Fluid Ht bikes models from 2020, here.
Model range prices
Norco Fluid HT+ 2.3 2020 is the cheapest bike model and costs 699$. Norco Fluid HT 1 29 2020 is the most expensive one and costs 1699$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2020 and its price was 1399$. Comparing the average cost of a Trail bike to this one, you will see that Fluid HT 2 29 price is 97.43% smaller.
Fluid HT 2 29 components
Fork
This bike has the SunTour XCR 34 fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the Fluid HT 2 29 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Norco Fluid HT 2 29 bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Norco Fluid HT 2 29 comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
