Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 20" -
Travel Front 63mm -
Fork Suntour XCT
-
Groupset SunRace -
Suspension Hardtail -
Drivetrain 1 × 6 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
20"
115cm - 129cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum HT
Suspension Fork
SR Suntour XCT Coil, 63mm Travel, Soft Spring, Adjustable Preload
Drivetrain
Rear Derailleur
SunRace RDM36
Shift Levers
SunRace Twist Shift
Cassette
SunRace MF, 14-28T, 6 Speed
Crank
Alloy 3 Piece, 28T Narrow Wide, 140mm
Bottom Bracket
Sealed Bearing Square Taper
Chain
KMC Z6
Pedals
Jr. MTB Flat, Black
Wheels
Front Hub
Aluminum, 9x100mm, 6 Bolt
Rear Hub
Aluminum, 10x135mm, HG, 6 Bolt
Rims
Aluminum Double Wall, 28H, 20"
Tires
Vee Crown Gem 2.25"
Brakes
Brakes
Mechanical Disc
Brake Levers
Alloy Jr., Reach Adjust
Disk Rotors
160mm
Cockpit
Stem
Alloy, 45mm Length 31.8mm Clamp
Handlebar
Alloy Jr. 540mm, 45mm Rise
Grips
Norco Youth
Headset
External Cup
Seat
Saddle
Norco Youth
Seatpost
Alloy 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 20" |
|---|---|
| Stack Reach Ratio | 1.27 mm |
| Bottom Bracket Height | 253 mm |
| Front Center | 566 mm |
| Rake | 40 mm |
| Stack | 409 mm |
| Reach | 321 mm |
| Top Tube Length | 449 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 255 mm |
| Head Tube Angle | 65 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 329 mm |
| Wheelbase | 895 mm |
| Bottom Bracket Drop | 7 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 129 cm |
About this model
Fluid HT 20.2 completes the Norco Fluid Ht model. There are 78 bikes that carry this model name. Take a sneak peek at all Norco Fluid Ht bikes models from 2022, by clicking here.
Model range prices
Norco Fluid HT 20.2 2022 is the cheapest bike model and costs 599$. Norco Fluid HT 1 27.5 2022 is the most expensive one and costs 1749$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Mountain bikes
Our math shows that the average cost of a dependable Mountain bike is 616$. However, you could also get a good Mountain bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Norco released this model in 2022, its price was 599$. Doing a quick comparison, we notice that Fluid HT 20.2 price is 2.84% lower than the average cost of a Mountain bike.
Fluid HT 20.2 components
Fork
This bike has the Suntour XCT fork installed. The fork’s travel is 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Norco Fluid HT 20.2 2022, has a 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid HT 20.2 is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Norco Fluid HT 20.2 2022 is available in one size only. In conclusion, make sure it fits you, or look for another model.
