Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox 35 Silver
-
Groupset Deore, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Removable, 900Wh, 720Wh and 540Wh Options -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, 130mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
Suspension Fork
RockShox 35 Silver R Coil, 140mm Travel, 44mm Offset, 1.8" Tapered, E-MTB
Rear Shock
X-Fusion 02 Pro R Air, Rebound Adjust, Custom Tune, 210x47.5mm
Drivetrain
Rear Derailleur
Shimano Deore RD-M5120
Shift Levers
Shimano Deore SL-M4100
Cassette
Shimano Deore CS-M4100, 11-46T, 10 Speed
Crank
Shimano, 34T, Narrow Wide, 165mm
Chain
KMC Anti-Rust E-MTB
Wheels
Front Hub
Alloy, 15x110mm Boost, 6-Bolt
Rear Hub
Alloy 12x148mm Boost, HG, 6 Bolt
Rims
WTB ST i30 TCS 2.0, 32H, 29"
Tires
Front: Goodyear Newton 2.4", Folding, Rear: Goodyear Newton 2.4", Folding
Brakes
Brakes
Front: Tektro HD-M285, Resin Pads, Rear: Tektro HD-M285, Resin Pads
Brake Levers
Tektro HD-M285
Cockpit
Stem
Alloy, 50mm Length, 35mm Clamp
Handlebar
Butted 6061 Alloy, 800mm, 25mm Rise
Grips
SDG Thrice Lock-On, Thin (S, M), Thick (L, XL)
Headset
FSA No. 55R, Sealed Bearing
Seat
Saddle
WTB Volt 250 Sport
Seatpost
TranzX YSP39 Dropper, 34.9mm, 125mm (S), 150mm (M) , 170mm (L, XL)
Motor & Battery
Motor
Shimano STEPS EP8
Battery
Removable, 900Wh, 720Wh and 540Wh Options
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.39 mm | 1.32 mm | 1.26 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 727 mm | 761 mm | 795 mm | 829 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 129 mm | 129 mm | 129 mm | 129 mm |
| Stack | 595 mm | 604 mm | 613 mm | 622 mm |
| Reach | 405 mm | 435 mm | 465 mm | 495 mm |
| Top Tube Length | 560 mm | 589 mm | 617 mm | 646 mm |
| Seat Tube Angle | 75.5 ° | 75.8 ° | 76.2 ° | 76.5 ° |
| Seat Tube Length | 395 mm | 415 mm | 440 mm | 485 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1183 mm | 1217 mm | 1251 mm | 1285 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 685 mm | 699 mm | 706 mm | 718 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
Model Overview
Fluid VLT A2 belongs to the Norco E Fluid model. There are 7 e-bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Norco Fluid VLT A2 2023 is the most affordable e-bike of this model and has a price of 3858$. On the other hand, Norco Fluid VLT A1 2023, is the most expensive and costs 4398$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
When Norco released this model in 2023, its price was 3858$. If we compare this with the average Trail e-bike cost we notice that the price is 14.65% higher.
Fluid VLT A2 components
Fork
The RockShox 35 Silver is included from the factory. It has a travel distance of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Fluid VLT A2 has a rear shock with a travel of 130mm. The model X-Fusion 02 Pro R Air is the one installed in this e-bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Norco Fluid VLT A2 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fluid VLT A2 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 4 sizes. They vary from 154 cm – 191 cm (5.05 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Fluid VLT A2. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
