Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
7005 alloy w/comfort stays & internal cables
Suspension Fork
SR Suntour M-3010 suspension fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney RD-TX55
Front Derailleur
Shimano Tourney FD-TX51
Shift Levers
N/A
Cassette
Shimano Altus CS-HG20 12-32T 7spd
Crank
Shimano Altus FC-M131C 48/38/28T
Bottom Bracket
Cartridge BB
Chain
KMC Z-50
Chain Tensioner
N/A
Pedals
Wellgo Resin Comfort Pedal w/ Kraton
Wheels
Front Hub
Joytech Alloy hub 32h - Silver
Rear Hub
Joytech Alloy hub w/Cassette 32h - Silver
Rims
Double wall alloy w/CNC side wall 32h - Silver
Tires
CST C-1096 700x35C
Brakes
Brakes
Tektro 837AL V-Brakes
Brake Levers
Shimano Altus Easy-Fire 51 w/4-finger levers
Disk Rotors
N/A
Cockpit
Stem
Alloy adjustable stem
Handlebar
Steel comfort high riser bar
Grips
Ergonomic w/Norco logo bar plug
Headset
Alloy threaded sealed bearing
Seat
Saddle
Selle Royal Loire Saddle
Seatpost
Alloy suspension seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.69 mm | 1.69 mm | 1.68 mm | 1.67 mm |
| Bottom Bracket Height | 292 mm | 292 mm | 292 mm | 292 mm |
| Front Center | 627 mm | 642 mm | 657 mm | 673 mm |
| Rake | 43 mm | 42 mm | 42 mm | 45 mm |
| Trail | 85 mm | 86 mm | 86 mm | 82 mm |
| Stack | 632 mm | 646 mm | 660 mm | 674 mm |
| Reach | 373 mm | 383 mm | 393 mm | 403 mm |
| Top Tube Length | 601 mm | 616 mm | 631 mm | 646 mm |
| Seat Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Seat Tube Length | 355 mm | 415 mm | 475 mm | 535 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 140 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 476 mm | 476 mm | 476 mm | 476 mm |
| Wheelbase | 1097 mm | 1111 mm | 1126 mm | 1144 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 746 mm | 773 mm | 798 mm | 823 mm |
| Front Travel | 63 mm | 63 mm | 63 mm | 63 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Malahat is part of the Norco Malahat model. Norco released 22 bikes variations of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Norco Malahat Step-Thru 2017 is the most affordable bike of this model and has a price of 429$. On the other hand, Norco Malahat 2017, is the most expensive and costs 429$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Hybrid bikes average price
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2017 and its price was 429$. In conclusion, this bike price is 31% lower than the price of the average Hybrid bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Malahat components
Fork
Norco Malahat 2017 bike is equipped with the SunTour fork, and has 63mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Norco Malahat 2017, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Malahat has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Malahat comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
