Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 alloy w/comfort stays & internal cables
Suspension Fork
SR Suntour M-3010 suspension fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney RD-TX55
Front Derailleur
Shimano Tourney FD-TX51
Shift Levers
Shift housing
Cassette
Shimano Altus CS-HG20 12-32T 7spd
Crank
Shimano Altus FC-M131C 48/38/28T
Bottom Bracket
Cartridge BB
Chain
KMC Z-50
Chain Tensioner
N/A
Pedals
Wellgo Resin Comfort Pedal w/ Kraton
Wheels
Front Hub
Joytech Alloy hub 32h - Silver
Rear Hub
Joytech Alloy hub w/Cassette 32h - Silver
Rims
Double wall alloy w/CNC side wall 32h - Silver
Tires
N/A
Brakes
Brakes
Tektro 837AL V-Brakes
Brake Levers
Shimano Altus Easy-Fire 51 w/4-finger levers
Disk Rotors
N/A
Cockpit
Stem
Alloy adjustable stem
Handlebar
Steel comfort high riser bar
Grips
Ergonomic w/Norco logo bar plug
Headset
Alloy threaded sealed bearing
Seat
Saddle
Norco Classic Comfort saddle
Seatpost
Alloy suspension seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.82 mm | 1.78 mm | 1.76 mm |
| Bottom Bracket Height | 292 mm | 292 mm | 292 mm |
| Front Center | 627 mm | 642 mm | 657 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 86 mm | 86 mm | 86 mm |
| Stack | 660 mm | 669 mm | 679 mm |
| Reach | 363 mm | 375 mm | 386 mm |
| Top Tube Length | 601 mm | 616 mm | 631 mm |
| Seat Tube Angle | 70 ° | 70 ° | 70 ° |
| Seat Tube Length | 355 mm | 415 mm | 475 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 170 mm | 180 mm | 190 mm |
| Chainstay Length | 476 mm | 476 mm | 476 mm |
| Wheelbase | 1096 mm | 1111 mm | 1126 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 633 mm | 601 mm | 570 mm |
| Front Travel | 63 mm | 63 mm | 63 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Malahat ST is part of the Norco Malahat model. There are 22 bikes that carry this model name. Check out the entire range from 2016 of this model, by clicking this link.
Model range prices
Norco Malahat 2016 is the cheapest bike model and costs 450$. Norco Malahat ST 2016 is the most expensive one and costs 450$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2016 for 450$. Doing a quick comparison, we notice that Malahat ST price is 24.89% smaller than the average cost of a Hybrid bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Malahat ST components
Fork
The fork installed on this bike is the SunTour model. The travel on this model is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on Malahat ST are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Malahat ST is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Malahat ST comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
