Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 125mm -
Fork RockShox Pike Ultimate
-
Groupset GX Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Front Triangle, Aluminum Rear, 125mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
Suspension Fork
RockShox Pike Ultimate RC2, DebonAir, 140mm Travel, 42mm Offset
Rear Shock
RockShox Super Deluxe Ultimate DH Custom RC, 190x45mm
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS
Shift Levers
SRAM GX Eagle AXS
Cassette
SRAM XG1275 Eagle, 10-52T
Crank
SRAM GX Eagle DUB Lunar, 32T, 170mm
Bottom Bracket
SRAM DUB PF92
Chain
SRAM GX Eagle
Wheels
Front Hub
Crank Bros. Synthesis E Carbon, 15x110mm Boost, 6-bolt
Rear Hub
Crank Bros. Synthesis E Carbon 12x148mm Boost, XD, 6 Bolt
Rims
Crank Bros. Synthesis E Carbon, 28H, 29"
Tires
Front: Vittoria Mazza 2.4" Trail G2.0, Rear: Vittoria Mazza 2.4" Trail G2.0
Brakes
Brakes
Front: SRAM Code RSC, 4 Piston, Organic Pads, Rear: SRAM Code RSC, 4 Piston, Organic Pads
Brake Levers
SRAM Code RSC
Cockpit
Stem
OneUp EDC Compatible, 50mm Length, 35mm Clamp
Handlebar
OneUp Carbon, 800mm, 20mm Rise
Grips
DMR Deathgrip
Headset
FSA Internal Sealed Bearing
Seat
Saddle
Fizik Alpaca Terra, Wingflex
Seatpost
X-Fusion Manic, 31.6mm, 125mm (S), 150mm (M,L), 170mm (XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.38 mm | 1.31 mm | 1.25 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 735 mm | 769 mm | 803 mm | 838 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 129 mm | 129 mm | 129 mm | 129 mm |
| Stack | 606 mm | 615 mm | 624 mm | 633 mm |
| Reach | 415 mm | 445 mm | 475 mm | 505 mm |
| Top Tube Length | 567 mm | 600 mm | 632 mm | 664 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 395 mm | 415 mm | 445 mm | 485 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 420 mm | 425 mm | 430 mm | 435 mm |
| Wheelbase | 1152 mm | 1191 mm | 1230 mm | 1270 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 659 mm | 675 mm | 693 mm | 714 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
About this model
Optic C AXS belongs to the Norco Optic model. There are 96 bikes that carry this model name. You can easily view all of the Norco Optic bikes models from 2023, here.
Model range prices
Norco Optic C3 2023 is the most economical model, with a starting price of 3699$. Norco Optic C AXS 2023 on the other hand costs 7199$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Norco Optic C AXS price was 7199$. Doing a quick comparison, we notice that Optic C AXS price is 160.64% more expensive than the average cost of a Trail bike.
Overview of components
Fork
Norco Optic C AXS 2023 bike is equipped with the RockShox Pike Ultimate fork, and has 140mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Optic C AXS has a rear shock with a travel of 125mm. The model RockShox Super Deluxe Ultimate DH Custom RC is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The Optic C AXS 2023 bike is equipped with 29″ carbon wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Optic C AXS has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 191 cm (5.05 ft – 6.27 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
