Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 110mm -
Fork RockShox Pike
-
Groupset XX, X0 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Optic Carbon 110mm (29), 120mm (650B) w/carbon seatstay
Suspension Fork
Rockshox Pike RCT 3 Solo Air Boost 120mm (29), 130mm (650B)
Rear Shock
Fox Factory Float w/Kashima DPS, EVOL
Drivetrain
Rear Derailleur
SRAM Eagle XX 1 12 speed
Front Derailleur
N/A
Shift Levers
SRAM Eagle XO 1 12 speed
Cassette
SRAM Eagle X01 10-50T
Crank
SRAM/Truvativ Stylo Eagle carbon Boost crank 32T (29), 34T (650B)
Bottom Bracket
SRAM GXP Pressfit BB 92
Chain
SRAM PC 12 speed chain
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
DT XMC 1200 wheelset boost 15x110mm
Rear Hub
DT XMC 1200 wheelset w/148x12mm
Rims
DTXCM 1200 Carbon w/30mm inner
Spokes
DT Swiss
Tires
Maxxis Forecaster 2.35 3C/EXO/TR
Brakes
Brakes
SRAM Guide Ultimate w/180mm rotor
Brake Levers
SRAM Guide Ultimate
Cockpit
Stem
Race Face Turbine w/CNC 50mm (29), 60mm (650B)
Handlebar
RaceFace Next R 800mmx20mm rise carbon, 35mm barbore
Grips
Ergon GA 30 lock on
Headset
FSA No 42 ACB 1.5" to 1-1/8"
Seat
Saddle
SDG Duster
Seatpost
Rockshox Reverb Stealth w/new lever, 100mm SM, 125mm M, 150mm L/XL, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.36 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm | 332 mm |
| Front Center | 692 mm | 717 mm | 743 mm | 769 mm |
| Rake | 52 mm | 51 mm | 50 mm | 50 mm |
| Trail | 92 mm | 93 mm | 94 mm | 94 mm |
| Stack | 594 mm | 591 mm | 600 mm | 610 mm |
| Reach | 407 mm | 434 mm | 457 mm | 479 mm |
| Top Tube Length | 564 mm | 595 mm | 625 mm | 655 mm |
| Seat Tube Angle | 75.4 ° | 74.9 ° | 74.5 ° | 74.1 ° |
| Seat Tube Length | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 93 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 418 mm | 423 mm | 428 mm | 433 mm |
| Wheelbase | 1107 mm | 1137 mm | 1168 mm | 1199 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 748 mm | 748 mm | 753 mm | 773 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Rear Travel | 110 mm | 110 mm | 110 mm | 110 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Optic C1 29 belongs to the Norco Optic model. There are 96 bikes that carry this model name. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
The most economical model, the Norco Optic A3 Womens 27.5 2018 has a starting price of 2299$. Norco Optic C1 29 2018 on the other hand is the most expensive at 6999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2018 for 6999$. In conclusion, this bike price is 267.4% higher than the price of the average Crosscountry bike.
Overview of components
Fork
The RockShox Pike is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Norco Optic C1 29 bike has the Fox Factory Float w/Kashima DPS model installed, and has a travel of 110mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the Optic C1 29 bike is equipped with the 29″ carbon model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Optic C1 29 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Optic C1 29 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Optic C1 29. Therefore, climbing or descending will be a breeze.
