Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 110mm -
Fork Fox Factory Float 34
-
Groupset GX Eagle, Truvativ Stylo -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Optic, Carbon Front Triangle and Seat Stay, Aluminum Chainstay and Linkarm, 110mm (29") | 120mm (27.5") Travel, Boost 12x148mm TA Dropouts
Suspension Fork
Fox 34 Factory, 130mm (29") | 140mm (27.5") Travel, Boost 15x110mm TA, Float Air Spring/Kashima Coating
Rear Shock
Fox Float DPS Factory, 190x50.8mm, EVOL/Kashima Coating
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12 Speed
Front Derailleur
-
Shift Levers
Rear: SRAM GX Eagle, 12 Speed, Front: -
Cassette
SRAM GX Eagle XG-1275, 10-50T, 12 Speed
Crank
Truvativ Stylo 7K DUB, 170mm (XS/S) | 175mm (M/L/XL), 30T
Bottom Bracket
SRAM DUB BB, PF92
Chain
SRAM NX Eagle, 12 Speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
DT 350 110x15 Boost sealed bearing disc hub
Rear Hub
DT Swiss 350, Boost 12x148mm, XD Driver
Rims
Race Face AR 27, 32 Hole, 27mm Internal Width
Spokes
DT Swiss Competition, butted 1.8/1.6/1.8, black, stainless steel
Tires
Maxxis Minion DHF, 2.3", 3C/EXO/TR, Folding
Brakes
Brakes
SRAM Guide RS, 4 Piston Hydraulic Disc, SRAM CenterLine 180mm Rotor
Brake Levers
SRAM Guide RS
Cockpit
Stem
Race Face Aeffect R, 35mm bar bore 50mm 29, 60mm 650B
Handlebar
Race Face Turbine R 35mm, 800mm, 20mm rise
Grips
Ergon GA20, Black
Headset
FSA No 42E/ACB 1.5” to 1-1/8” w/black FSA logos
Seat
Saddle
SDG Radar Mtn with chromoly rails
Seatpost
TranzX YSP12JL Stealth Dropper, 80mm (XS) | 100mm (S) | 125mm (M) | 150mm (L/XL) Travel, 31.6mm, 1x Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.39 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 695 mm | 720 mm | 746 mm | 773 mm |
| Rake | 47 mm | 46 mm | 45 mm | 45 mm |
| Trail | 101 mm | 102 mm | 103 mm | 103 mm |
| Stack | 597 mm | 595 mm | 604 mm | 613 mm |
| Reach | 402 mm | 429 mm | 452 mm | 474 mm |
| Top Tube Length | 567 mm | 597 mm | 626 mm | 655 mm |
| Seat Tube Angle | 74.7 ° | 74.4 ° | 74 ° | 73.7 ° |
| Seat Tube Length | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 93 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 418 mm | 423 mm | 428 mm | 433 mm |
| Wheelbase | 1106 mm | 1136 mm | 1167 mm | 1198 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 754 mm | 746 mm | 751 mm | 766 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Optic C1 29 is part of the Norco Optic model. There are 96 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Norco Optic A1 Women’s 29 2019 is the most affordable bike of this model and has a price of 3499$. On the other hand, Norco Optic C1 29 2019, is the most expensive and costs 5249$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Norco Optic C1 29 price was 5249$. Comparing this to the average Crosscountry bike price, we see that the price is 175.54% higher.
Optic C1 29 components
Fork
The Optic C1 29 comes factory-installed with the Fox Factory Float 34 fork. This has a travel range of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Norco Optic C1 29 bike has the Fox Float DPS Factory model installed, and has a travel of 110mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the Optic C1 29 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Optic C1 29 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Norco Optic C1 29 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
