Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 110mm -
Fork RockShox Pike RC
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Optic, Carbon Front Triangle, Aluminum Chainstay, Seat Stay and Linkarm, 110mm (29") | 120mm (27.5") Travel, Boost 12x148mm TA Dropouts
Suspension Fork
RockShox Pike RC, 130mm (29") | 140mm (27.5") Travel, Boost 15x110mm TA, Charger 2 Damper
Rear Shock
Fox Float DPS Performance Elite, 190x50.8mm, EVOL
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12 Speed
Front Derailleur
-
Shift Levers
Rear: SRAM NX Eagle, 12 Speed, Front: -
Cassette
SRAM NX Eagle PG-1230, 11-50T, 12 Speed
Crank
SRAM NX Eagle, 170mm (XS/S) | 175mm (M/L/XL), 32T
Bottom Bracket
SRAM DUB BB, PF92
Chain
SRAM NX Eagle, 12 Speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Novatec D711SB Boost 110x15 sealed bearing disc hub
Rear Hub
DT Swiss 370, Boost 12x148mm
Rims
WTB ST i29 TCS 2.0, 32 Hole, 29mm Internal Width
Spokes
Sapim, butted, stainless steel
Tires
Maxxis Minion DHF, 2.3", EXO/TR, Folding
Brakes
Brakes
SRAM Level T, 2 Piston Hydraulic Disc, SRAM CenterLine 180mm Rotor
Brake Levers
SRAM Level T
Cockpit
Stem
Alloy 6061 35mm bar bore, 50mm 29, 60mm 650B
Handlebar
Norco 20 mm rise 6061, 35mm bar bore 800mm x 20mm rise
Grips
Ergon GA20, Black
Headset
FSA No 42E/ACB 1.5” to 1-1/8” w/black FSA logos
Seat
Saddle
SDG Radar Mtn saddle
Seatpost
TranzX YSP12JL Stealth Dropper, 80mm (XS) | 100mm (S) | 125mm (M) | 150mm (L/XL) Travel, 31.6mm, 1x Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM |
|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.45 mm |
| Bottom Bracket Height | 338 mm | 338 mm |
| Front Center | 664 mm | 690 mm |
| Rake | 44 mm | 43 mm |
| Trail | 107 mm | 109 mm |
| Stack | 575 mm | 584 mm |
| Reach | 380 mm | 403 mm |
| Top Tube Length | 532 mm | 561 mm |
| Seat Tube Angle | 75.2 ° | 74.9 ° |
| Seat Tube Length | 380 mm | 410 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° |
| Head Tube Length | 97 mm | 107 mm |
| Chainstay Length | 417 mm | 422 mm |
| Wheelbase | 1081 mm | 1112 mm |
| Bottom Bracket Drop | 14 mm | 14 mm |
| Standover Height | 767 mm | 762 mm |
| Wheels | 29" | 29" |
Model Overview
Optic C2 27.5 is a Norco Optic model. Norco released 96 bikes variations of this model so far. You can easily view all of the Norco Optic bikes models from 2019, here.
Model range prices
Norco Optic A1 Women’s 29 2019 is the cheapest bike model and costs 3499$. Norco Optic C1 Women 27.5 2019 is the most expensive one and costs 5249$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2019 for 3999$. Comparing this to the average Crosscountry bike price, we see that the price is 109.92% higher.
Optic C2 27.5 components
Fork
The RockShox Pike RC is included from the factory. It has a travel distance of 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the Fox Float DPS Performance Elite model, with a travel of 110mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Optic C2 27.5 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Optic C2 27.5 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Dropper post
Norco Optic C2 27.5 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
