Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Elite Float 34
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Optic Trail frame 120mm travel
Suspension Fork
FOX 34 Float Performance Elite 650B 110x15mm boost 130mm travel
Rear Shock
Fox Float DPS Peformance Elite EVOL
Drivetrain
Rear Derailleur
Shimano XT long cage 11 speed for 2x11
Front Derailleur
Shimano XT 2x11 FD side swing front pull
Shift Levers
N/A
Cassette
Shimano 11-40T 11sp (running change to 11-42T)
Crank
Race Face Turbine Cinch 2x11 36/26T Boost crank (with 1x32T single cinch ring included)
Bottom Bracket
Race Face Pressfit BB 92
Chain
Shimano HG-600-11 11sp
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
SRAM MTH 716 15x110mm
Rear Hub
SRAM MTH 746 148x12mm XD
Rims
RaceFace AR 24 650B tubeless compatible
Tires
Nobby Nic front and rear 2.35 with SnakeSkin. Trailstar Compound, TL
Brakes
Brakes
Shimano Deore XT hydraulic disc 180mm rotor
Brake Levers
Shimano Deore XT
Disk Rotors
N/A
Cockpit
Stem
Race Face Turbine Basic 35 60mm length
Handlebar
Race Face Turbine 760x20mm
Grips
Norco lock on grip
Headset
Cane Creek 10 Series
Seat
Saddle
SDG Circuit Mtn with chromoly rails
Seatpost
Rockshox Reverb stealth 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.43 mm | 1.37 mm | 1.33 mm | 1.28 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 660 mm | 687 mm | 713 mm | 739 mm | 765 mm |
| Rake | 44 mm | 44 mm | 44 mm | 45 mm | 44 mm |
| Trail | 104 mm | 104 mm | 104 mm | 103 mm | 104 mm |
| Stack | 572 mm | 581 mm | 590 mm | 599 mm | 609 mm |
| Reach | 385 mm | 407 mm | 430 mm | 452 mm | 475 mm |
| Top Tube Length | 529 mm | 559 mm | 589 mm | 619 mm | 649 mm |
| Seat Tube Angle | 75.9 ° | 75.5 ° | 75 ° | 74.5 ° | 74.1 ° |
| Seat Tube Length | 380 mm | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 97 mm | 107 mm | 117 mm | 127 mm | 137 mm |
| Chainstay Length | 417 mm | 422 mm | 427 mm | 432 mm | 437 mm |
| Wheelbase | 1077 mm | 1108 mm | 1139 mm | 1171 mm | 1202 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 747 mm | 747 mm | 747 mm | 757 mm | 777 mm |
| Front Travel | 130 mm | 130 mm | 130 mm | 130 mm | 130 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Optic C7.2 is part of the Norco Optic model. Norco released 96 bikes variations of this model so far. Take a sneak peek at all Norco Optic bikes models from 2017, by clicking here.
Model range prices
The most economical model, the Norco Optic A7.2 2017 has a starting price of 2599$. Norco Optic C7.1 Eagle 2017 on the other hand is the most expensive at 7699$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Norco Optic C7.2 price was 5199$. If we compare this with the average Trail bike cost we notice that the price is 88.23% higher.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Elite Float 34 model. The travel on this model is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Norco Optic C7.2 bike has the Fox Float DPS Peformance Elite EVOL model installed, and has a travel of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Norco Optic C7.2 2017, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Optic C7.2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Norco Optic C7.2 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Norco model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
