Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 110mm -
Fork RockShox Revelation RC
-
Groupset GX, SRAM -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Optic Trail frame 110mm travel
Suspension Fork
Rockshox Revelation RL 100x15mm 120mm travel
Rear Shock
Fox Float DPS Performane EVOL
Drivetrain
Rear Derailleur
SRAM GX 1
Front Derailleur
N/A
Shift Levers
N/A
Cassette
SRAM XG 1150 10-42T
Crank
SRAM FC S-1000 32T
Bottom Bracket
SRAM Pressfit BB 92
Chain
SRAM PC 1130 11sp
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
SRAM MTH 716 15x110mm
Rear Hub
SRAM MTH 746 148x12mm XD
Rims
Alex DP 23 29 I23 tubeless compatible
Tires
Schwalbe Nobby Nic 29x2.35 DC front and rear
Brakes
Brakes
SRAM Level T hydraulic brake w/180mm rotor
Brake Levers
SRAM Level T
Disk Rotors
N/A
Cockpit
Stem
Alloy 3D forged 50mm length
Handlebar
Norco 6061 DB alloy 760mmx25mm
Grips
Norco lock on grip
Headset
Cane Creek 10 Series
Seat
Saddle
SDG Circuit Mtn with steel rails
Seatpost
KS E-Ten Integra adj post w / remote stealth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.36 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm | 332 mm |
| Front Center | 692 mm | 717 mm | 743 mm | 769 mm |
| Rake | 52 mm | 51 mm | 50 mm | 50 mm |
| Trail | 92 mm | 93 mm | 94 mm | 94 mm |
| Stack | 594 mm | 591 mm | 600 mm | 610 mm |
| Reach | 407 mm | 434 mm | 457 mm | 479 mm |
| Top Tube Length | 564 mm | 595 mm | 625 mm | 655 mm |
| Seat Tube Angle | 75.4 ° | 74.9 ° | 74.5 ° | 74.1 ° |
| Seat Tube Length | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 93 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 418 mm | 423 mm | 428 mm | 433 mm |
| Wheelbase | 1107 mm | 1137 mm | 1168 mm | 1199 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 748 mm | 748 mm | 753 mm | 773 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Rear Travel | 110 mm | 110 mm | 110 mm | 110 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Optic C9.3 is part of the Norco Optic model. Norco launched 96 bikes of this model so far. You can easily view all of the Norco Optic bikes models from 2017, here.
Model range prices
Norco Optic A9.2 2017 is the most economical model, with a starting price of 2599$. Norco Optic C7.1 2017 on the other hand costs 7699$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Norco Optic C9.3 price was 3799$. If we compare this with the average Crosscountry bike cost we notice that the price is 99.42% more expensive.
Overview of components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Fox Float DPS Performane EVOL, with a travel distance of 110mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The Optic C9.3 2017 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Optic C9.3 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Optic C9.3. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
