Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 150mm -
Fork Fox Performance Float 36
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Range, Aluminum, 150mm (29") | 160mm (27.5") Travel, Boost 12x148mm TA Dropouts
Suspension Fork
Fox 36 Performance, 170mm (29") | 180mm (27.5") Travel, Boost 15x110mm TA, Float Air Spring
Rear Shock
Fox Performance Float DPX2 with LV and EVOL
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12 Speed
Front Derailleur
-
Shift Levers
Rear: SRAM NX Eagle, 12 Speed, Front: -
Cassette
SRAM NX Eagle PG-1230, 11-50T, 12 Speed
Crank
Truvativ Decendent 6K DUB, 170mm (XS/S) | 175mm (M/L/XL), 30T
Bottom Bracket
SRAM DUB BB, Threaded BSA 73mm
Chain
SRAM NX Eagle, 12 Speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Novatec 110x15 sealed bearing disc hub
Rear Hub
DT Swiss 370, Boost 12x148mm
Rims
WTB ST i29 TCS 2.0, 32 Hole, 29mm Internal Width
Spokes
DT Swiss Competition stainless steel butted
Tires
Maxxis Minion DHF, 2.5" WT, EXO/Dual Compound, Folding
Brakes
Brakes
SRAM Code R, 4 Piston Hydraulic Disc, SRAM CenterLine 200mm Rotor
Brake Levers
SRAM Code R
Cockpit
Stem
Alloy 6061 40mm stem
Handlebar
Race Face Turbine R 35mm, 800mm, 20mm rise
Grips
VP, Lock-On
Headset
FSA No. 57 Zero Stack ZS44/56, sealed cartridge bearing
Seat
Saddle
SDG Radar Mtn with CR-MO rails
Seatpost
TranzX YSP12JL Stealth Dropper, 80mm (XS) | 100mm (S) | 125mm (M) | 150mm (L/XL) Travel, 31.6mm, 1x Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.49 mm | 1.43 mm | 1.38 mm | 1.33 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 705 mm | 731 mm | 758 mm | 785 mm | 812 mm |
| Rake | 42 mm | 44 mm | 43 mm | 43 mm | 44 mm |
| Trail | 123 mm | 121 mm | 122 mm | 122 mm | 121 mm |
| Stack | 594 mm | 594 mm | 604 mm | 613 mm | 622 mm |
| Reach | 375 mm | 399 mm | 422 mm | 445 mm | 467 mm |
| Top Tube Length | 537 mm | 566 mm | 595 mm | 625 mm | 654 mm |
| Seat Tube Angle | 74.8 ° | 74.4 ° | 74 ° | 73.7 ° | 73.3 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 417 mm | 422 mm | 427 mm | 432 mm | 437 mm |
| Wheelbase | 1122 mm | 1153 mm | 1185 mm | 1217 mm | 1249 mm |
| Bottom Bracket Drop | 9 mm | 9 mm | 9 mm | 9 mm | 9 mm |
| Standover Height | 799 mm | 789 mm | 787 mm | 788 mm | 789 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Range A1 27.5 is a Norco Range model. There are 82 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
The most economical model, the Norco Range A2 27.5 2019 has a starting price of 3099$. Norco Range C1 29 2019 on the other hand is the most expensive at 5850$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2019 for 3699$. Comparing this to the average Enduro bike price, we see that the price is 2.78% more expensive.
Overview of components
Fork
Norco Range A1 27.5 2019 bike is equipped with the Fox Performance Float 36 fork, and has 170mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is Fox Performance Float DPX2 with LV and EVOL, with a travel distance of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on Range A1 27.5 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Range A1 27.5 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Norco Range A1 27.5 includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
