Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Performance Elite Float 36
-
Groupset XX1 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Range 650B carbon 160 mm travel
Suspension Fork
Fox 36 Performance Elite 170mm 15mm 3pos
Rear Shock
Cane Creek Double Barrel piggyback air w/climb switch
Drivetrain
Rear Derailleur
SRAM XX1 11 sp long cage
Front Derailleur
N/A
Shift Levers
N/A
Cassette
SRAM XG 1180 10-42T 11 sp
Crank
SRAM XX1 carbon crank w/X Sync 30T ring
Bottom Bracket
SRAM Pressfit BB92
Chain
SRAM PC 1130 11 sp
Chain Tensioner
MRP AMG 28-32T
Pedals
N/A
Wheels
Front Hub
DT EX 1501 Spline One Wheelset
Rear Hub
DT EX 1501 Spline One Wheelset
Rims
DT EX 1501 Spline One wheelset EX Enduro
Tires
N/A
Brakes
Brakes
SRAM Guide RS C
Brake Levers
SRAM Guide RS C
Disk Rotors
N/A
Cockpit
Stem
Race Face Atlas 50mm stem, 35 mm clamp
Handlebar
Race Face SixC 800mm carbon bar 35mm
Grips
SDG ODI USA lock on grips
Headset
Cane Creek 40 series tapered (integrated)
Seat
Saddle
SDG Bel Air 2.0 w/chromoly rail
Seatpost
Rockshox Reverb Stealth seatpost 30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.45 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 706 mm | 729 mm | 753 mm | 777 mm |
| Rake | 42 mm | 42 mm | 42 mm | 41 mm |
| Trail | 115 mm | 115 mm | 115 mm | 116 mm |
| Stack | 599 mm | 608 mm | 617 mm | 626 mm |
| Reach | 399 mm | 418 mm | 438 mm | 458 mm |
| Top Tube Length | 578 mm | 604 mm | 631 mm | 658 mm |
| Seat Tube Angle | 73.2 ° | 72.8 ° | 72.4 ° | 72.1 ° |
| Seat Tube Length | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 427 mm | 431 mm | 435 mm | 439 mm |
| Wheelbase | 1133 mm | 1160 mm | 1189 mm | 1216 mm |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm |
| Standover Height | 770 mm | 771 mm | 773 mm | 777 mm |
| Front Travel | 170 mm | 170 mm | 170 mm | 170 mm |
| Rear Travel | 160 mm | 160 mm | 160 mm | 160 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Range C7.1 completes the Norco Range model. Norco released 82 bikes variations of this model so far. Check out the entire range from 2016 of this model, by clicking this link.
Model range prices
Norco Range A7.2 2016 is the most economical model, with a starting price of 2750$. Norco Range C7.1 2016 on the other hand costs 7250$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2016 and its price was 7250$. Comparing the average cost of an Enduro bike to this one, you will see that Range C7.1 price is 101.44% higher.
Range C7.1 components
Fork
Norco Range C7.1 2016 bike is equipped with the Fox Performance Elite Float 36 fork, and has 170mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the Cane Creek Double Barrel piggyback air w/climb switch rear shock model, which has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The Range C7.1 2016 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Range C7.1 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Norco Range C7.1 comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
